2009 Victory Kingpin 8-Ball
Back to 2009 Victory Motorcycle Index Page
Click photos to enlarge.
They make great desktop images.
2009 Victory Kingpin 8-Ball
2009 Victory Kingpin 8-Ball
• 2009 Victory Kingpin 8-Ball
2009 Victory Kingpin 8-Ball
It’s easy to overlook the fact these 8-Balls deliver the best value on the Cruiser market because they’re loaded with outstanding Victory performance and tremendous style.
New for 2009
– New Stingray cast wheels that are 13.8 lbs lighter
– New LED tail light is twice as bright
Key Features
– Value positioned Classic Cruiser introduced in 2008
Blacked Out:
– Wheels, bars, foot controls, engine, forks, triples, belt guard, pulley, strut covers, mirrors, brakes
– Cruiser Headlight
– 5 Speed
No passenger seat or pegs
Features & Benefits
• Blacked-out freedom 100 Cubic Inch V-Twin Engine
• Black aluminum wheels
• Black accents
• Classic flared fenders
• Inverted forks
• Driver full floorboards
• 8-Ball fender graphic
• Classic styled headlight
• Mutli LED Tail light
• Stingray billet wheels
2009 Victory Kingpin 8-Ball – USA Specifications
MSRP $13,999.00*
ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters
Displacement 100 ci (1,634 cc)
Bore x Stroke 101 x 102 mm
Compression Ratio 8.7:1
Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies
Clutch Wet, multi-plate
Cooling Air / oil
Exhaust Staggered slash-cut dual exhaust with crossover
DIMENSIONS
Length 99.9 in. (2,537 mm)
Weight Dry: 657 lbs. (298 kg)
GVWR: 1,234 lbs. (560 kg)
Ground Clearance 5.8 in. (148 mm)
Wheelbase 65.6 in. (1,666 mm)
Fuel Capacity 4.5 gal. (17 l)
Oil Capacity 5 qt. (4.75 l)
Seat Height 26.5 in. (673 mm)
DRIVETRAIN
Transmission 5-speed constant mesh
Primary Drive Gear drive with torque compensator
Final Drive Carbon fiber reinforced belt
Suspension Front: Inverted cartridge telescopic fork, 43 mm fork tube; 5.1 in. (130 mm) travel
Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, preload adjustable spring; 3.9 in. (100 mm) travel
BRAKES/WHEELS/TIRES
Brakes Front: 300 mm floating rotor with 4-piston caliper
Rear: 300 mm floating rotor with 2-piston caliper
Tires Front: 130/70 B18 Dunlop 491 Elite II
Rear: 180 55-B18 Dunlop D417
Rake 32.8°
Trail 5.4 in. (138 mm)
Colors Black with 8-Ball decal
2009 Victory Kingpin 8-Ball – Canada Specifications
MSRP C$15,609.00
ENGINE
Engine 4-stroke, 50° V-twin, single overhead camshafts with 4-valves per cylinder, self-adjusting cam chains, hydraulic lifters
Displacement 100 ci (1,634 cc)
Bore x Stroke 101 x 102 mm
Compression Ratio 8.7:1
Fuel System Electronic Fuel Injection with dual 45 mm throttle bodies
Clutch Wet, multi-plate
Cooling Air / oil
Exhaust Staggered slash-cut dual exhaust with crossover
DIMENSIONS
Length 99.9 in. (2,537 mm)
Weight Dry: 657 lbs. (298 kg)
GVWR: 1,234 lbs. (560 kg)
Ground Clearance 5.8 in. (148 mm)
Wheelbase 65.6 in. (1,666 mm)
Fuel Capacity 4.5 gal. (17 l)
Oil Capacity 5 qt. (4.75 l)
Seat Height 26.5 in. (673 mm)
DRIVETRAIN
Transmission 5-speed constant mesh
Primary Drive Gear drive with torque compensator
Final Drive Carbon fiber reinforced belt
Suspension Front: Inverted cartridge telescopic fork, 43 mm fork tube; 5.1 in. (130 mm) travel
Rear: Single, mono-tube gas shock, cast aluminum with rising rate linkage swingarm, preload adjustable spring; 3.9 in. (100 mm) travel
BRAKES/WHEELS/TIRES
Brakes Front: 300 mm floating rotor with 4-piston caliper
Rear: 300 mm floating rotor with 2-piston caliper
Tires Front: 130/70 B18 Dunlop 491 Elite II
Rear: 180 55-B18 Dunlop D417
Rake 32.8°
Trail 5.4 in. (138 mm)
Colors Black with 8-Ball decal
