2007 BMW K1200R

Back to 2007 BMW Motorcycle Index Page

Click photos to enlarge for detail.
They make great desktop images.

2007 BMW K1200R
2007 BMW K1200R

2007 BMW K1200R
2007 BMW K1200R

2007 BMW K1200R
2007 BMW K1200R

2007 BMW K1200R
2007 BMW K1200R

2007 BMW K1200R
2007 BMW K1200R

2007 BMW K1200R
2007 BMW K1200R

– 2007 BMW K1200R

2007 BMW K1200R

The cure for power deficit disorder.

Never before has a naked bike served up this much raw power. Packing a 163 horsepower punch, the all-attitude K 1200 R is the ultimate hooligan bike. With a look that screams pure aggression, and a motor that lays power to the ground like nobody’s business, one thing’s for sure, this is a BMW motorcycle that blows the helmet off of everyone’s expectations.

Outrageously powerful. The ultimate naked bike. The new BMW K1200R is the most masculine means of transport ever. It boasts unreasonable output of 163 bhp and a maximum torque of 127 Nm. These naked figures mean that acceleration from 0 to 100 km/h takes place in a mere 2.9 seconds with the aid of the newly developed 6-speed gearbox. The BMW Motorrad Duolever and Paralever suspension ensures total control and easy handling in spite of the bike’s enormous power. The BMW Motorrad EVO brake system (optionally available with BMW Motorrad Integral ABS) has been especially adapted to meet the needs of such naked power and safeguards highest-level safety. In addition the suspension can be optimally adjusted to your riding style and the prevailing road surface thanks to the ESA* suspension adjustment system – even while you’re riding.

* Optional extra



MSRP*: $18,000.00 Canada
MSRP: $13,900 USA

*Freight, retailer preparation & taxes extra.





Standard Equipment

Hazard Warning Flashers

Single Key Locks

Closed Loop 3 Way Catalytic Converter

Side Stand with Starter Inhibition

Adjustable Handbrake and Clutch Levers

Diagnostic Interface

Electronic Immobilizer

Info Flat Screen

Power Socket




Specifications USA

Engine
Type Transverse mounted, liquid-cooled inline 4-cylinde
Bore x Stroke 79 mm x 59 mm
Displacement 1157 cc
Horsepower 163 bhp @ 10250 rpm
Torque 94 lb/ft @ 8250 rpm
Compression Ratio 13.0 :1
Valve Gear DOHC, chain-driven with bucket tappets
Valves 2 x 32 mm mm intake / 2 x 27,5 mm mm exhaust
Valves / Cylinder Four
Engine Oil Capacity 3.7 quarts
Engine Management BMW Engine Controller – BMS K
Fuel Requirement Unleaded, premium grade, 93 AKI
Fuel Tank HDPE, internal pump and internal filter
Fuel Capacity 5.0 U.S. gallons including 1 gallon reserve
Charging System 580 Watts @ 14 Volts
Battery 12 Volts 14 Amps/hour low maintenance
Cooling System Single Radiator, 50/50 water/anti-freeze mix
Drivetrain
Primary Drive 1:1.559
Clutch 151 mm, multi-disc oil bath
1st Gear Ratio 2.52:1
2nd Gear Ratio 1.84:1
3rd Gear Ratio 1.45:1
4th Gear Ratio 1.28:1
5th Gear Ratio 1.14:1
6th Gear Ratio 1.01:1
Final Drive System Enclosed driveshaft with two universal joints
Final Drive Ratio 2.91:1
Frame and Suspension
Frame Composite aluminum frame
Front Suspension BMW Duolever
Front Travel 4.5 inches
Rear Suspension BMW EVO Paralever
Rear Travel 5.3 inches
Brakes
Brake System BMW EVO
Front Brakes Two, four-piston fixed calipers
Front Rotor 12.6 inch dual floating rotors
Rear Brake Single, two-piston fixed caliper
Rear Rotor 10.4 inch single, fixed rotor
Actuation Method Hydraulic, DOT 4 fluid type
Wheels and Tires
Front Wheel 3.50 x 17 cast alloy, five double-spoke
Rear Wheel 5.50 x 17 cast alloy, five double-spoke
Front Tire 120/70 x 17 tubeless
Rear Tire 180/55 x 17 tubeless
Dimensions
Overall Length 87.7 inches
Overall Width 33.7 inches
Wheelbase 62.2 inches
Ground Clearance Info. Unavailable
Seat Height 32.3 inches
Steering Angle 61.0 degrees
Front Wheel Trail 4.5 inches
Weight – Dry 465 lbs.
Weight – Wet 522 lbs.
Maximum Load 992 lbs. GVWR
Standard Colors
Code  Price Description
841     N / C Sun Yellow
946     N / C Dark Graphite Metallic
954     N / C White Aluminum Metallic
Standard Equipment
Available Equipment
173     $275.00 Sport wheels
416     $800 Electronic Suspension Adjustment (ESA)
519     $235 Heated Hand Grips
530     $260 Tire Pressure Monitoring (TPM)
539     $275 On Board Computer (incl. Oil Level Warning)
560     $210.00 Windshield Sport
588     $50.00 White Turn Indicator
603     $235 Anti-Theft Alarm
630     $1040.00 Integral ABS II
665     $135.00 Luggage Grid
774     $N / C Dual Bench Seat – Low (31.1 inches)



Specifications Canada:
BMW K1200R

Engine
Type . . . . . . . . . . . . . . . . . . . . . . . Water-cooled, four-stroke-in-line-
four-cylinder-engine, dual camshaft,
four valves per cylinder
Bore x stroke. . . . . . . . . . . . . . . . . 79 mm x 59 mm
Capacity. . . . . . . . . . . . . . . . . . . . 1,157 ccm
Output. . . . . . . . . . . . . . . . . . . . . . 120 kW (163 bhp) at 10,250 rpm
Max. torque . . . . . . . . . . . . . . . . . 127 Nm at 8,250 rpm
Compression ratio . . . . . . . . . . . . 13.0 : 1
Fuel/engine management . . . . . . . Butterfly valve electronic fuel injection system / BMW Motorrad BMS-K engine management
Emission control . . . . . . . . . . . . . Regulated 3-way catalytic converter
Performance/fuel consumption
Maximum speed. . . . . . . . . . . . . . Over 200 km/h (124 mph)
Fuel consumption per 100 km (62 mls.)
at a constant 90 km/h (56 mph) . . 4.7 l
at a constant 120 km/h (75 mph) . . 5.5 l
Fuel type . . . . . . . . . . . . . . . . . . . . . . . Premium plus unleaded 98 octane (RON)
Electrics
Alternator. . . . . . . . . . . . . . . . . . . 580 W generator
Battery . . . . . . . . . . . . . . . . . . . . . 12 V / 14 A
Power transmission
Clutch. . . . . . . . . . . . . . . . . . . . . . Hydraulically operated multi-disc
wet clutch
Gearbox . . . . . . . . . . . . . . . . . . . . Synchromesh 6-speed gearbox
Secondary drive . . . . . . . . . . . . . . Cardan (shaft drive)
Chassis/brakes
Frame. . . . . . . . . . . . . . . . . . . . . . Bridge frame in aluminium with
load-bearing engine
Front suspension. . . . . . . . . . . . . . BMW Motorrad Duolever; central
suspension strut, rebound damping electronically adjustable via ESA*
* Optional extra
** As defined in EU directive 93/93/EEC, filled with all operating fluids, fuelled to at least 90% of usable tank capacity.
*** Unladen weight without fuel/operating fluids.
Rear suspension. . . . . . . . . . . . . . Die-cast aluminium single-sided
swinging arm with BMW Motorrad Paralever; central spring strut, con-
tinuously variable hydraulic spring
preload adjustment via handwheel, electronic suspension adjustment, adjustable rebound damping (with ESA*
suspension adjustment compression and rebound damping is electronic)
ESA* (Electronic Suspension
Adjustment) . . . . . . . . . . . . . . . . . Damping can be easily switched by pressing a button between presets
(at the rear in the traction and compression
phase, at the front in the traction phase) in relation to the
preset basic suspension setting
Travel front/rear. . . . . . . . . . . . . . . 115 mm / 135 mm
Wheelbase (in normal position) . . 1,580 mm
Castor (in normal position). . . . . . 101 mm
Steering head angle
(in normal position) . . . . . . . . . . . 61°
Wheels . . . . . . . . . . . . . . . . . . . . . Cast aluminium
Rims, front . . . . . . . . . . . . . . . . . . 3.50 x 17
Rims, rear. . . . . . . . . . . . . . . . . . . 5.50 x 17
Tyres, front . . . . . . . . . . . . . . . . . . 120/70 ZR 17
Tyres, rear. . . . . . . . . . . . . . . . . . . 180/55 ZR 17
Brakes, front. . . . . . . . . . . . . . . . . Dual disc EVO brake system with
floating discs and four-piston fixed
caliper (diameter: 320-mm)
Brakes, rear. . . . . . . . . . . . . . . . . . Single disc brake with double-piston fixed caliper (diameter: 265-mm)
ABS* . . . . . . . . . . . . . . . . . . . . . . BMW Motorrad Integral ABS
(part-integral version)
Dimensions/weights
Seat height, unladen . . . . . . . . . . 820 mm (lowered seat* 790 mm)
Unladen, road ready, fully fuelled** 237 kg
Dry weight*** . . . . . . . . . . . . . . . 211 kg
Max. permitted weight . . . . . . . . . 450 kg
Max. load with standard equipment 213 kg
Usable tank volume . . . . . . . . . . . 19 l
Reserve . . . . . . . . . . . . . . . . . . . . Approx. 4 l
Length . . . . . . . . . . . . . . . . . . . . . 2,228 mm
Height (without mirrors). . . . . . . . 1,230 mm
Width (with mirrors) . . . . . . . . . . . 856 mm

Specifications and features are subject to change
