2003 Suzuki GSX 1300 R Hayabusa

2003 Suzuki GSX 1300 R Hayabusa



– 2003 Suzuki GSX 1300 R Hayabusa

Sportbike HAYABUSA™ 1300 – 2003 GSX1300RK3

Titanium-nitride-coated inner fork tubes for reduced friction and improved appearance.
Gold-colored brake calipers for improved appearance.

KEY FEATURES:

– Aerodynamic fairing design with low drag coefficient. All fairing components have been designed for reduced drag and turbulence.

– Compact 4-stroke, four-cylinder liquid-cooled engine with DOHC, 16-valves, Twin Swirl Combustion Chambers, plus gear-driven counterbalancer for smooth operation.

– Electronic fuel injection system, fed by 46mm throttle bodies and ram air intake with large volume airbox.

– Lightweight shim-under-bucket valve train with narrow 14 degree valve angle for high combustion chamber efficiency.

– High efficiency liquid cooling system for optimum engine operating temperature, including compact air-cooled oil cooler and oil-jet piston cooling.

– SCEM (Suzuki Composite Electro-chemical Material) plated cylinders minimize cylinder size and improve heat dissipation.

– 6-speed transmission with high-capacity clutch featuring back-torque limiter system for smooth downshifts and scissors-type primary gear for reduced gear noise.

– Large volume 4-into-2 exhaust system with stainless steel head pipes and lightweight aluminum silencers.

– Digital direct-ignition system combines an ignition coil with each spark plug cap for reduced weight and stronger spark.

– Full instrumentation with ultra-thin step-motor construction. Includes fuel gauge, clock, temperature gauge, LCD odometer and twin tripmeters with fuel consumption gauge.

– Unique, vertically mounted dual headlight provides a bright, wide beam with a 60W projector-type high-beam and a 55W low-beam halogen bulb.

– Rigid twin-spar aluminum frame minimizes weight while maintaining high torsional strength.

– Large diameter (43mm) inverted front forks with fully adjustable compression & rebound damping and spring preload, plus steering damper.

– Proven link-type rear suspension with remote reservoir shock absorber. Rear suspension features fully adjustable rebound damping and compression damping and spring preload.

– Bridge-type swingarm with large diameter swingarm pivot shaft provides high swingarm rigidity.

– Powerful front disc brakes with large 320mm discs and 6-piston calipers.

– Rear disc brake with 240mm disc and 2-piston caliper.

– Radial tires mounted on lightweight 3-spoke aluminum wheels. Wide 190-size rear tire is mounted on 6″ wide rim.

– Hinged fuel tank simplifies maintenance and provides easy access to the airbox and air filter.

SPECIFICATIONS
MSRP: $10,849.00
Engine: 1299cc, 4-stroke, four-cylinder, liquid-cooled, DOHC, 16-valve, TSCC. 175 hp (129 kW)/ 9800 rpm, 141 Nm/ 7 000 rpm.
Warranty:12 month unlimited mileage limited warranty.
Bore & Stroke:81.0 x 63.0mm
Compression ratio:11.0:1
Fuel System:Keihin/Denso Fuel Injection
Lubrication:Wet sump
Ignition:Digital/Transistorized
Starter:Electric
Transmission:6-speed, constant mesh
Final Drive:#530 chain
Overall Length: 2140mm (84.3 in.)
Overall Width: 740mm (29.1 in.)
Overall Height:1155mm (45.5 in.)
Seat Height:805mm (31.7 in.)
Ground Clearance:120mm (4.7 in.)
Wheelbase:1485mm (58.5 in.)
Dry Weight:217kg (478 lbs.) 218kg (480 lbs.) CA. model

Suspension:
FRONT:Inverted telescopic, coil spring, fully adjustable spring preload, 14-way adjustable rebound damping and 13-way adjustable compression damping
REAR:Link-type, gas/oil damped, fully adjustable spring preload, 22-way adjustable compression & rebound damping

Brakes:
FRONT:Dual hydraulic disc
REAR:Single hydraulic disc

Tires:
FRONT:120/70-ZR-17
REAR:190/50-ZR-17
Fuel Tank Capacity:21 liter (5.5 gal.) 19.0 liter (5.0 gal.) CA. model
Color:Black/Gray, Silver/Gray

Specifications are subject to change without notice, in accordance with national regulation and legislations.
