2017 Victory Hammer S Review

2017 Victory Hammer S on www.Totalmotorcycle.com

PRO STREET PERFORMANCE…

Drop the hammer on the competition with the Hammer S, the most aggressive cruiser in Victory’s lineup. Equipped with a big-block Freedom® 106 V-Twin engine, burly inverted fork and a pair of strong-stopping four-piston brake calipers that look like they came off of a sportbike, extra wide pro stock-inspired 250-series rear rubber, a sleek rear cowl with a hideaway passenger pad and bodywork wrapped in musclecar racing stripes, the Hammer S is a streetfighter with an American soul.

Pro Street Performance.

2017 Victory Hammer S www.Totalmotorcycle.com
Key Features

Smoke the competition with sportbike-type suspension, pro stock-inspired
rear rubber, and sleek bodywork.

– Four-Valve Heads & Overhead Cams
– 250-Series Rear Tire
– Inverted Front Fork With Dual Disc Brakes
– Musclecar Inspired Paint Design

2017 Victory Hammer S www.Totalmotorcycle.com
Features and Benefits

Pro stock-inspired 250-width rear tire

This isn’t a fat rear tire. This is a muscular Dunlop® that grips
the road and never lets go.

Dual Disc Brakes

Strong-stopping, four-piston brake calipers deliver braking performance to
match the power output of the big-block Freedom 106 V-twin engine.

Inverted Fork

Sportbike-type suspension, with an inverted fork up front, wouldn’t look
out of place on a race track.

Racing Style Paint

This muscle car inspired paint design compliments the overall style of this
cruiser.

2017 Victory Hammer S – www.Totalmotorcycle.com
USA Specifications/Technical Details
US MSRP Price: Available in Gloss Black with White Racing Stripes ($15,599).

Specifications

ABS/Cruise Control Not Equipped
Curb Weight 673 lbs / 305 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Charging System 38 Amps Max Output
Compression Ratio 9:4:1
Cooling Air & Oil
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Exhaust Dual-Large Bore Slash-Cut with Common Volume
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Transmission/Final Drive Carbon Fiber Reinforced Belt
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission Type 6 Speed Overdrive/Constant Mesh
Valve Train SOHC – 4 Valves per Cylinder/Hydraulic Lifters & Cam Chain
Adjusters
Bore x Stroke (mm) 101 x 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Front Suspension Telescopic Fork/ 5.1″ (130mm)
Rear Suspension Single Monotube Gas/Preload Adjustable/3.9″ (98.9mm)

Brakes

Brake System Type Not Linked
Front Brakes Dual 300 x 5mm/Floating Rotor/4 Piston Calipers
Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper

Tires / Wheels

Front Tires Dunlop D418F Elite 3 130/70R18 63H
Front Wheel 18 x 3.5 in
Rear Tires Dunlop D419 Elite 3 250/40R18 81V
Rear Wheel 18 x 8.5 in

DIMENSIONS

Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
GVWR 1,173 lbs / 532 kg
Ground Clearance 5.8 in / 148 mm
Rake/Trail 33° / 5.5 in / 140 mm
Seat Height 26.5 in / 673 mm
Wheelbase 66.5 in / 1689 mm
Overall Length (in./mm.) 93.8 in / 2382 mm

Features

Color Swatch Gloss Black w/White Racing Stripes
Colors (Base) Gloss Black w/White Racing Stripes

2017 Victory Hammer S – www.Totalmotorcycle.com
Canadian Specifications/Technical Details
Canada MSRP Price: $18,499 CDN

ABS Not Equipped
Dry Weight 673 lbs / 305 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Valve Train SOHC – 4 Valves per Cylinder/Hydraulic Lifters & Cam Chain
Adjusters
Transmission Type 6 Speed Overdrive/Constant Mesh
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Dual-Large Bore Slash-Cut with Common Volume
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Cooling Air & Oil
Compression Ratio 9:4:1
Charging System 38 Amps Max Output
Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Bore x Stroke (mm) 101 x 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Rear Suspension Single Monotube Gas/Preload Adjustable/3.9″ (98.9mm)

Front Suspension Telescopic Fork/ 5.1″ (130mm)

Brakes

Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper
Front Brakes Dual 300 x 5mm/Floating Rotor/4 Piston Calipers
Brake System Type Not Linked

Tires / Wheels

Rear Wheel 18 x 8.5 in
Rear Tires Dunlop D419 Elite 3 250/40R18 81V
Front Wheel 18 x 3.5 in
Front Tires Dunlop D418F Elite 3 130/70R18 63H

DIMENSIONS

Wheelbase 66.5 in / 1689 mm
Seat Height 26.5 in / 673 mm
Rake/Trail 33° / 5.5 in / 140 mm
Ground Clearance 5.8 in / 148 mm
GCWR 1,173 lbs / 532 kg
Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
Overall Length (in./mm.) 93.8 in / 2382 mm

Features

Colors (Base) Gloss Black w/White Racing Stripes
Color / Graphics Gloss Black w/White Racing Stripes

2017 Victory Hammer S – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £TBA GBP (On The Road inc 20% Vat)

TBA

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
