2017 Victory Gunner Review

2017 Victory Gunner on www.Totalmotorcycle.com

SUPERIOR FIREPOWER …

Take aim at the competition with this modern bobber, inspired by the original bobbers built by returning World War II vets who were hungry to recreate the adrenaline rush of flying a P-51 Mustang® fighter plane. Powered by the 106 cubic-inch Freedom® V-Twin mated to a smooth-shifting six-speed overdrive transmission, the Gunner has enough torque – 110 ft.-lb., in fact – available for takeoff. Combine that performance with the confidence inspiring riding position gained from a low 25-inch solo saddle and pullback handlebars, and you have the ideal recipe for a performance bobber. The old days were never this good.

Superior Firepower.

2017 Victory Gunner www.Totalmotorcycle.com
Key Features

Modern Bobber delivering superior firepower through our best selling Freedom
106 V-Twin Engine.

• Freedom 106 V-Twin Delivering 110 Ft.-Lb. of Torque
• Solo Saddle, Slammed 25-Inch Seat Height
• Six-Speed Transmission With Overdrive

2017 Victory Gunner www.Totalmotorcycle.com
Features and Benefits

106 Cubic-Inch Freedom® V-Twin

The Freedom® 106 V-twin is a modern motor with overhead cams and four
valves per cylinder—no pushrods here.

6-Speed Overdrive Transmission

Blow away everything on the road with this 6-Speed Overdrive Transmission.
Shift smoothly, powerfully, and confidently whether on the highway or downtown.

24 Spoke Cast Aluminum Wheels

The Gunner’s aim is true on premium 24-spoke cast aluminum wheels.

Low Seat Height & Relaxed Ergonomics

A confident riding position is created by the low, 25-inch seat height and
pullback handlebars.

2017 Victory Gunner – www.Totalmotorcycle.com
USA Specifications/Technical Details
US MSRP Price: Available in Suede Titanium Metallic ($13,499 USD) and Suede
Sagebrush Green Metallic ($13,899 USD).

Specifications

ABS/Cruise Control Not Equipped
Curb Weight 682 lbs / 310 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Valve Train 4 Valves per Cylinder, Hydraulic Lifters & Cam Chain Adjusters

Transmission Type 6 Speed Overdrive/Constant Mesh
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Dual-Staggered Slash-Cut with Common Volume
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Cooling Air & Oil
Compression Ratio 9.4:1
Charging System 38 Amps Max Output
Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Bore x Stroke (mm) 101 X 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Rear Suspension Single Monotube Gas/Preload Adjustable/3.0″ (75mm)
Front Suspension Telescopic Fork/ 5.1″ (130mm)

Brakes

Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper
Front Brakes Single 300 x 5mm/ Floating Rotor/ 4 Piston Caliper
Brake System Type Not Linked

Tires / Wheels

Rear Wheel 16 x 3.5 in
Rear Tires Dunlop 491 E2-RWL 140/90 B16 77H
Front Wheel 16 x 3.5 in
Front Tires Dunlop 491 E2-RWL 130/90 B16 67H

DIMENSIONS

Wheelbase 64.8 in / 1647 mm
Seat Height 25.0 in / 635 mm
Rake/Trail 32° / 6.7 in (170.0 mm)
Ground Clearance 4.7 in / 120 mm
GVWR 1151 lbs / 523 kg
Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
Overall Length (in./mm.) 93.4 in / 2372 mm

Features

Colors (Base) Suede Titanium Metallic, Suede Sagebrush Green Metallic
Color Swatch Suede Titanium Metallic

2017 Victory Gunner – www.Totalmotorcycle.com
Canadian Specifications/Technical Details
Canada MSRP Price: $15,499 CDN

ABS Not Equipped
Dry Weight 682 lbs / 310 kg
Displacement 106 ci / 1731 cc
Oil Capacity 5.0 qts / 4.73 ltr

ENGINE & DRIVETRAIN

Valve Train 4 Valves per Cylinder, Hydraulic Lifters & Cam Chain Adjusters

Transmission Type 6 Speed Overdrive/Constant Mesh
Transmission/Primary Drive Gear Drive with Torque Compensator
Transmission/Final Drive Carbon Fiber Reinforced Belt
Fuel System Electronic Fuel Injection with dual 45mm throttle body
Exhaust Dual-Staggered Slash-Cut with Common Volume
Drive/Driven Clutch Wet Multi-Plate/Diaphragm Spring
Cooling Air & Oil
Compression Ratio 9.4:1
Charging System 38 Amps Max Output
Battery YTX20HL-BS/12 Volt 18 Amp Hour 310 CCA
Bore x Stroke (mm) 101 X 108 mm
Engine Type Freedom 106/ 6 V-Twin

Suspension

Rear Suspension Single Monotube Gas/Preload Adjustable/3.0″ (75mm)
Front Suspension Telescopic Fork/ 5.1″ (130mm)

Brakes

Rear Brakes Single 300 x 5mm/ Floating Rotor/ 2 Piston Caliper
Front Brakes Single 300 x 5mm/ Floating Rotor/ 4 Piston Caliper
Brake System Type Not Linked

Tires / Wheels

Rear Wheel 16 x 3.5 in
Rear Tires Dunlop 491 E2-RWL 140/90 B16 77H
Front Wheel 16 x 3.5 in
Front Tires Dunlop 491 E2-RWL 130/90 B16 67H

DIMENSIONS

Wheelbase 64.8 in / 1647 mm
Seat Height 25.0 in / 635 mm
Rake/Trail 32° / 6.7 in (170.0 mm)
Ground Clearance 4.7 in / 120 mm
GCWR 1151 lbs / 523 kg
Fuel Capacity (Litres) 4.5 gal / 17.0 ltr
Overall Length (in./mm.) 93.4 in / 2372 mm

Features

Colors (Base) Suede Titanium Metallic, Suede Sagebrush Green Metallic
Color / Graphics Suede Titanium Metallic

2017 Victory Gunner – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £TBA GBP (On The Road inc 20% Vat)

TBA

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
