2017 Can-Am Spyder RT-S Review

2017 Can-Am Spyder RT-S

2017 Can-Am Spyder RT-S

2017 Can-Am Spyder RT-S

2017 Can-Am Spyder RT-S

2017 Can-Am Spyder RT-S Review

2017 Can-Am Spyder RT-S on www.Totalmotorcycle.com

GETAWAY VEHICLE…

As the premium open-air ultimate touring vehicle, the Spyder RT-S goes the extra mile with an adjustable rear air suspension and a premium passenger experience.

Adds even more comfort with plush adjustable air suspension, passenger amenities and high-end lighting.

Spyder RT-S

Open your road with unmatched comfort for two riders and luxurious styling.

2017 Can-Am Spyder RT-S www.Totalmotorcycle.com Key Features

Spyder RT
Rotax 1330 ACE in-line 3 cylinders, high torque engine
Vehicle Stability System with ABS, traction control and stability control
ECO mode smart assist
Ultra comfort touring saddle and driver backrest ready
Adjustable passenger footboards
41 gallons (155 L) of storage
12-spoke, Metallic Silver front wheels
AM / FM audio system with USB port and plug (Jack 1/8)for cell and MP3 player
Anti-theft system
Dynamic Power Steering
Premium color digital gauge
Comfort features like electronic cruise control, heated rider handgrips, adjustable electric windshield and more

SPYDER RT-S
ALL SPYDER RT FEATURES PLUS:
Adjustable rear air suspension
Rider footboards
12-spoke, Carbon Black Satin front wheels
Refined front fenders with integrated LED lights
Fog lamps and accent lights
Carbon Black and Satin Chrome parts
Heated passenger grips with control
Front cargo light and liner
Secondary gauges (fuel information, engine temperature)

TRANSMISSION AND COLORS AVAILABLE:
6-speed semi-automatic with reverse (SE6)

PEARL WHITE
CHAMPAGNE METALLIC
ORBITAL BLUE METALLIC

2017 Can-Am Spyder RT-S www.Totalmotorcycle.com Features and Benefits

DESIGN ELEMENTS

EXTRA ATTITUDE

An intense look from low-profile tires wrapped around 12-spoke carbon black satin wheels, and premium front fenders with integrated LED light pipes. The Spyder RT-S model also hosts Satin Chrome accents for a striking look.

RIDER FOOTBOARDS

VARY YOUR POSITION

You get more foot positions with these vibration-damping driver footboards, a real benefit on long rides.

PREMIUM FRONT CARGO

ILLUMINATE
AND PROTECT

A light and felt insert add a nice finishing touch to the trademark Spyder front cargo compartment.

RT LUXURY FEATURES

CHANGE WITH THE WEATHER

Activate the cruise control, then sit back and enjoy the scenery. Thermal rider grips keep your hands warm, while an electric adjustable windshield enables you to quickly react to changing weather conditions.

AUDIO SYSTEM

ON-ROAD ENTERTAINMENT

Your favorite tunes are the perfect complement to the open road. AM/FM radio and iPod input drives the 4-speaker audio system. Plus, the passenger gets their own volume control.

2017 Can-Am Spyder RT-S – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $28,499* USD (*Transport and preparation not included)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† twin-tube shock absorbers /
6.9 in. (174 mm)
Rear suspension Swing arm
Rear shock type / Travel .
SACHS twin-tube shock absorber
with pneumatic preload adjustment /
6 in. (152 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo†
4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims 12-spoke Metallic Silver, 15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Metallic Silver, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 105 x 61.9 x 59.4 in.
(2,667 x 1,572 x 1,510 mm)
Wheelbase . 67.5 in. (1,714 mm)
Seat height 30.4 in. (772 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 1,012 lb (459 kg)
Storage capacity . . . . . . . . . 41 gal (155 L)
Maximum vehicle load . 494 lb (224 kg)
Fuel capacity . 6.9 gal (26 L)
Reserve 1 gal (3.8 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Premium color digital gauge: digital speedometer,
tachometer, odometer, trip & hour meters, gear
position, ECO™ mode smart assist, temperature,
engine lights, electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55-W)
Windshield . Touring – Electric adjustment
Wind deflectors Standard
Cruise control Electronic
Seat . Ultra comfortable with lumbar support
and passenger backrest
Rider heated grips Standard
Audio system
4 speakers (2 – 5 1/4″ in front + 2 – 4 1/2″ in rear)
come with USB port located in the rear top cargo
and aux. plug (Jack 1/8) for cell and MP3 player
Power outlet USB plug
Towing capacity . 400 lb (182 kg)
Trims and parts
Metallic Silver: Rider footpegs, adjustable
passenger footboards and footpeg support,
handlebar, rear sprocket wheel, front and rear
shocks springs, exhaust tip and heat shield
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended B.E.S.T. available from
12 to 36 months

2017 Can-Am Spyder RT-S – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $32,199 CDN (Transport and preparation not included)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† twin-tube shock absorbers /
6.9 in. (174 mm)
Rear suspension Swing arm
Rear shock type / Travel .
SACHS twin-tube shock absorber
with pneumatic preload adjustment /
6 in. (152 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo†
4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims 12-spoke Metallic Silver, 15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Metallic Silver, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 105 x 61.9 x 59.4 in.
(2,667 x 1,572 x 1,510 mm)
Wheelbase . 67.5 in. (1,714 mm)
Seat height 30.4 in. (772 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 1,012 lb (459 kg)
Storage capacity . . . . . . . . . 41 gal (155 L)
Maximum vehicle load . 494 lb (224 kg)
Fuel capacity . 6.9 gal (26 L)
Reserve 1 gal (3.8 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Premium color digital gauge: digital speedometer,
tachometer, odometer, trip & hour meters, gear
position, ECO™ mode smart assist, temperature,
engine lights, electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55-W)
Windshield . Touring – Electric adjustment
Wind deflectors Standard
Cruise control Electronic
Seat . Ultra comfortable with lumbar support
and passenger backrest
Rider heated grips Standard
Audio system
4 speakers (2 – 5 1/4″ in front + 2 – 4 1/2″ in rear)
come with USB port located in the rear top cargo
and aux. plug (Jack 1/8) for cell and MP3 player
Power outlet USB plug
Towing capacity . 400 lb (182 kg)
Trims and parts
Metallic Silver: Rider footpegs, adjustable
passenger footboards and footpeg support,
handlebar, rear sprocket wheel, front and rear
shocks springs, exhaust tip and heat shield
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended B.E.S.T. available from
12 to 36 months

2017 Can-Am Spyder RT-S – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: £24,199 GBP (On The Road inc 20% Vat)

ENGINE
Type
Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled
with electronic fuel injection and electronic
throttle control
Bore & stroke . . . . . . . . . . . . 3.31 x 3.14 in. (84 x 80 mm)
Power . 115 hp (85.8 kW) @ 7250 RPM
Torque 96 lb-ft. (130.1 Nm) @ 5000 RPM
CHASSIS
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† twin-tube shock absorbers /
6.9 in. (174 mm)
Rear suspension Swing arm
Rear shock type / Travel .
SACHS twin-tube shock absorber
with pneumatic preload adjustment /
6 in. (152 mm)
Electronic brake
distribution system Foot-operated, hydraulic 3-wheel brake
Front brakes 270 mm discs with Brembo†
4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake Electrically actuated
Front tires MC165/55R15 55H
Rear tire . MC225/50R15 76H
Aluminum front rims 12-spoke Metallic Silver, 15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Metallic Silver, 15 x 7 in. (381 mm x 178 mm)
DIMENSIONS
L x W x H 105 x 61.9 x 59.4 in.
(2,667 x 1,572 x 1,510 mm)
Wheelbase . 67.5 in. (1,714 mm)
Seat height 30.4 in. (772 mm)
Ground clearance . 4.5 in. (115 mm)
Dry weight . 1,012 lb (459 kg)
Storage capacity . . . . . . . . . 41 gal (155 L)
Maximum vehicle load . 494 lb (224 kg)
Fuel capacity . 6.9 gal (26 L)
Reserve 1 gal (3.8 L) approx.
Fuel type Premium unleaded

FEATURES
Instrumentation
Premium color digital gauge: digital speedometer,
tachometer, odometer, trip & hour meters, gear
position, ECO™ mode smart assist, temperature,
engine lights, electronic fuel gauge, clock
Running lights . 2 halogen headlamps (55-W)
Windshield . Touring – Electric adjustment
Wind deflectors Standard
Cruise control Electronic
Seat . Ultra comfortable with lumbar support
and passenger backrest
Rider heated grips Standard
Audio system
4 speakers (2 – 5 1/4″ in front + 2 – 4 1/2″ in rear)
come with USB port located in the rear top cargo
and aux. plug (Jack 1/8) for cell and MP3 player
Power outlet USB plug
Towing capacity . 400 lb (182 kg)
Trims and parts
Metallic Silver: Rider footpegs, adjustable
passenger footboards and footpeg support,
handlebar, rear sprocket wheel, front and rear
shocks springs, exhaust tip and heat shield
SAFETY & SECURITY
SCS . Stability Control System
TCS Traction Control System
ABS . Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security System (D.E.S.S.™)
WARRANTY
Factory 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended B.E.S.T. available from
12 to 36 months

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
