2017 Beta Evo 200 Review

2017 Beta Evo 200

2017 Beta Evo 200

2017 Beta Evo 200

2017 Beta Evo 200 Review

2017 Beta Evo 200 on www.Totalmotorcycle.com

Limited Numbers Built…

Featuers new styling for 2017

Perfect starter bike yet also ideal for experienced riders

Hydraulic clutch

6-speed transmission

Easy to start

Built in limited numbers

Great bike for all levels

Only 200cc Trail in class

2017 Beta Evo 200 www.Totalmotorcycle.com Key Features

Versions:

Standard Evo
• Hydro-formed aluminum frame with fuel in the frame
• Reversed flywheel moves weight mass to the center of the bike providing more balance
• Tightest turning radius of all other brands

Evo SS
-“Hi-Torque” exhaust system
-Heavier flywheel to help smooth out the power.
-Smaller countershaft sprocket to tie the engine torque to the ground
-Slower turn throttle assemble
-Different combustion chamber to reduce the engine’s power pulses
-Heavier primary drive gear for additional smoothness.

EVO Sport
• Designed for slow speed trail riding
• Long range seat/tank for more longer, more comfortable rides
• Knobby tires provide better traction on the trail
• Hand guards for protection

2017 Beta Evo 200 www.Totalmotorcycle.com Features and Benefits

2017 Beta Evo 200 – www.Totalmotorcycle.com North American Specifications/Technical Details
US MSRP Price: $7199 USD

Engine Specs:

Type: Single cylinder, 2-stroke, liquid-cooled w/ reed valve
Bore: 64mm
}Stroke: 60.5mm
Displacement: 194.6 cc
Compression Ratio: 11.8:1
Ignition: Electronic 12 volt, 85 watt w/ dual-map switch (aggressive or soft settings)
Spark Plug NGK BR7ES
Lubrication: Pre-mix (synthetic oil) }
Carburetor: Keihin PWK 28mm
Clutch: Wet multi-disc w/ cush-drive basket
Transmission: 6-speed


..

Chassis Specs:

Frame: Aluminum beam, single wave Hydro-Formed w/built in fuel tank
Wheelbase: 51.4” }
Seat Height: 26”
Ground Clearance: 12.2”
Footrest Height: 13.6”
Dry Weight: 145 lbs. dry
Fuel Tank Capacity: .75 US gallons
Front Suspension: 38mm Paioli
Rear Suspension: Adjustable single shock, aluminum bodied, with nitrogen valve including linkage
Front Wheel Travel: 6.5”
Rear Wheel Travel: 7.1”
Final Gearing: 11t front, 42t rear
Front Brake: 185mm rotor w/ 4-piston caliper
Rear Brake: 160mm rotor w/ twin-piston caliper
Front/Rear Rim: 21” (Front) 18” (Rear)
Front/Rear Tire: Michelin Trial
Warranty: 6 month Limited Warranty
MSRP: $7199.00 *specifications subject to change without notice.
