2016 Can-Am Spyder F3T Review

2016 Can-Am Spyder F3T on www.Totalmotorcycle.com

A THRILLING RIDE WITH A HIGHER DOSE OF STYLE…

Unique “S” signature trim, machined wheels, premium fenders and suede seat take the muscular design to another level.

While you’re enjoying the thrilling and confident ride of the Spyder F3-S, onlookers will be admiring its special machined deep black high gloss front wheels, suede seat and added fender lighting.

When it’s time for an extended Spyder F3 cruise, the new F3-T is your bike. You get the added comfort of a tall windshield and big bore SACHS shocks. Then take along your stuff with a new glovebox and integrated hard side luggage.

2016 Can-Am Spyder F3T www.Totalmotorcycle.com Key Features

SPYDER F3 STANDARD FEATURES

Rotax 1330 ACE in-line 3 cylinders, high torque engine
Vehicle Stability System with ABS, traction control and stability control
High-performance Brembo† braking system
Gas-charged, aluminum, FOX† PODIUM† front shocks
ECO™ mode smart assist
UFit custom fitting system (rider footpegs and handlebars)
6-spoke, Metallic Silver front wheels
Anti-theft system
Dynamic Power Steering

TRANSMISSIONS AND COLOR AVAILABLE:
6-speed manual with reverse (SM6)
6-speed semi-automatic with reverse (SE6)

STEEL BLACK METALLIC

SPYDER F3-S

ALL SPYDER F3 FEATURES PLUS:
Cruise control
6-spoke, machined Deep Black high gloss front wheels
Refined front fenders with integrated LED lights
Black embossed suede seat with Red stitching and “S” tab
Deep Black high gloss rear wheel
Distinctive “S” trim signature

PEARL WHITE

CAN-AM RED
SOLID GLOSS
PURE MAGNESIUM METALLIC WITH CAN-AM RED FRAME

SPYDER F3-S SPECIAL SERIES

ALL SPYDER F3-S FEATURES PLUS:
6-spoke, Black Chrome front wheels
Black perforated seat with Black stitching
Exclusive Triple Black coloration and graphics
Unique Special Series signature trims
*Shown with optional Urban Rack

TRANSMISSIONS AND COLOR AVAILABLE:
ONLY 6-speed semi-automatic with reverse (SE6)

MONOLITH BLACK SATIN

2016 Can-Am Spyder F3T www.Totalmotorcycle.com Features and Benefits

ROTAX 1330 ACE ENGINE

POWERFUL AND EFFICIENT

The Rotax 1330 ACE engine is an in-line triple-cylinder configuration for maximum torque in every gear, to deliver excellent roll-on acceleration and throttle response. It’s also efficient, with the ability to ride up to 252 miles (406 km) on a single tank*. Plus, it’s extremely low maintenance.

*Tested at constant speed. Fuel mileage may vary depending personal riding habits, weather conditions, trip length, vehicle condition, vehicle configuration and other conditions. Break-in mileage may vary.

6-SPEED TRANSMISSION

SMOOTH OPERATOR

This 6-speed transmission offers the perfect balance of comfort and fuel economy thanks to a sophisticated hydraulic clutch system. Cruise comfortably at low RPMs with your choice of manual or semi-automatic transmission. Both include reverse. The semi-automatic version uses thumb and index finger paddle shifting.

VEHICLE STABILITY SYSTEM

OPTIMUM CONTROL

Developed in partnership with BOSCH and inspired by automotive technologies, the Vehicle Stability System integrates anti-lock brakes, traction control, and stability control for confidence taking on the open road.

SACHS BIG-BORE SHOCKS

ENGINEERED FOR A SMOOTHER RIDE

These premium wide-diameter shocks ensure a plush ride even on bumpy backcountry roads and are quiet at all speeds.

UFIT SYSTEM

TAILOR YOUR BIKE

The exclusive Spyder F3 UFit system lets you
easily position the footpegs according to your
height and choose the handlebar based on
your preferred riding style — ensuring a truly
customized riding experience.
*Custom handlebar sold as an accessory.

BREMBO BRAKING SYSTEM

SERIOUS STOPPING POWER

Higher-performance brakes specifically designed for Can-Am Spyder from the world leader in braking technology ensure excellent stopping power and consistent performance every time.

CARGO SPACE

BRING
MORE

In addition to the trademark Spyder front cargo area, there is a new glove box and two smartly-styled hard side luggage cases for a total of 21 gallons (78 L) of cargo capacity.

PREMIUM COLOR DIGITAL GAUGE

YOUR ESSENTIALS, IN FULL COLOR

A vivid, full-colour digital screen allows quick access to key vehicle information such as speed, trip distance, and RPMs.

AUDIO SYSTEM

ON-ROAD ENTERTAINMENT

Music and cruising were made for each other. AM/FM radio with USB and AUX inputs for cell and MP3 player, located in the glove box, drives four speakers up front. (Option on F3-T)

PREMIUM WHEELS

TWO-TONE PERFECTION

Designed specifically for the Spyder F3, these wheels evoke boldness and confidence. They’re machined, deep black high gloss, for a super-premium look. You also get the front fenders with integrated LED light pipes for greater visibility and a striking look.

SEATING

MODERN STYLE, PLUSH COMFORT

All-black saddle features perforated leather and contrasting red stitching for a sleek, modern look. Delivers-all-day comfort and excellent lumbar support.

CONVENIENT CONSOLE

SLEEK
PROTECTION

On long rides, you’ll appreciate the added wind protection and convenience from the low tinted windshield, integrated rear-view mirrors and glove box.

TRAILER READY

ROAD TRIP READY

This Spyder model is ready to pull a Can-Am Freedom or RT-622 trailer to take along everything you need. Each trailer includes a plug-in module that adds a trailer mode to our VSS vehicle stability system. This ensures you get the same peace-of-mind riding with the trailer as you do without it.

2016 Can-Am Spyder F3T – www.Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $22999 USD

/ ENGINE /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually) / 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake
distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tires MC165 / 55R15 55H
Rear tire MC225 / 50R15 76H
Aluminum front rims ………. 6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium color digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
RT-622 and Freedom Towing capacity of 400 lb (181 kg)
trailer capability
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 gal (27 L)
Reserve 1.2 gal (4.5 L) approx.
Fuel type Premium unleaded
/ WARRANTY /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended . B.E.S.T. available from
12 to 36 months

2016 Can-Am Spyder F3T – www.Totalmotorcycle.com Canadian Specifications/Technical Details
Canada MSRP Price: $26299 CDN

/ ENGINE /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually) / 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake
distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tires MC165 / 55R15 55H
Rear tire MC225 / 50R15 76H
Aluminum front rims ………. 6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminum rear rim . Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium color digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
RT-622 and Freedom Towing capacity of 400 lb (181 kg)
trailer capability
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 gal (27 L)
Reserve 1.2 gal (4.5 L) approx.
Fuel type Premium unleaded
/ WARRANTY /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance
Extended . B.E.S.T. available from
12 to 36 months

2016 Can-Am Spyder F3T – www.Totalmotorcycle.com European Specifications/Technical Details
Europe/UK MSRP Price: Starting from £20499 GBP (On The Road inc 20% Vat)

/ Engine /
Type . Rotax® 1330 ACE™ in-line 3 cylinders, liquid-cooled with
electronic fuel injection and electronic throttle control
Bore & stroke . 3.31 x 3.14 in. (84 x 80 mm)
Power 115 hp (86 kW) @ 7250 RPM
Torque 96 lb-ft. (130 Nm) @ 5000 RPM
/ CHASSIS /
Front suspension Double A-arms with anti-roll bar
Front shocks type / Travel SACHS† Big-Bore shock absorbers / 5.1 in. (129 mm)
Rear suspension . Swing-arm with basic monoshock
Rear shock type / Travel SACHS shock absorber with adjustable air preload
(manually)/ 5.2 in. (132 mm)
Electronic brake Foot-operated, hydraulic 3-wheel brake distribution system
Front brakes . 270 mm discs with Brembo† 4-piston fixed calipers
Rear brake . 270 mm disc, 1-piston floating caliper
with integrated parking brake
Parking brake . Electrically actuated
Front tyres MC165 / 55R15 55H
Rear tyre MC225 / 50R15 76H
Aluminium front rims ……..6-spoke, Machined Deep Black high gloss front wheels,
15 x 5 in. (381 x 127 mm)
Aluminium rear rim Deep Black, 15 x 7 in. (381 mm x 178 mm)
/ FEATURES /
Instrumentation ………………Premium colour digital gauge: Digital speedometer,
tachometer, odometer, trip & hour meters, gear position,
ECO™ mode smart assist, temperature, engine lights,
electronic fuel gauge, clock
Running lights 2 halogen headlamps (55 / 60-W)
Windshield Tinted
Cruise control Electronic
Trims and parts ……………….. Chrome Satin and Carbon Black: Rear sprocket wheel,
front and rear shocks springs, exhaust tip and heat shield
/ SAFETY & SECURITY /
SCS Stability Control System
TCS Traction Control System
ABS Anti-lock Braking System
DPS™ Dynamic Power Steering
Anti-theft system . Digitally Encoded Security
System (D.E.S.S.™)
/ DIMENSIONS /
L x W x H …………………………102.2 x 58.9 x 48.9 in.
(2,596 x 1,497 x 1,241 mm)
Wheelbase 67.3 in. (1,709 mm)
Seat height 26.6 in. (675 mm)
Ground clearance 4.5 in. (115 mm)
Dry weight 948 lb (430 kg)
Storage capacity 20.6 US gal (78 L)
Maximum vehicle load 439 lb (199 kg)
Fuel capacity 7.1 US gal (27 L)
Reserve 1.2 US gal (4.5 L) approx.
Fuel type Premium unleaded
/ Warra nty /
Factory . 2-year BRP Limited Warranty
with 2-year roadside assistance

*Starting at MSRP is the manufactured suggested price and excludes delivery, setup, tax, title, license, and additional fees and expenses. Bikes may be shown with optional accessories. Final sale price determined by an authorized dealer. Specifications and MSRP are subject to change.

Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
