– 2012 KTM 690 Enduro R Review

2012 KTM 690 Enduro R

A HARD ENDURO FOR ALL CHALLENGES

Can you say “Hard Enduro”? What you mean is “LC4”. The KTM LC4 models have always made their mark in this category. Low weight, great performance, rugged off-road technology and the utmost reliability have always been their core values, and that is just
what makes the current 690 R the great bike that it is. A generous 250mm of suspension travel iron out even the deepest potholes. The slightly decreased travel slightly lowers the 690 Enduro R’s centre of gravity in MY2012, giving it an even more balanced ride – as dynamic as always but even more comfortable.

Competent Continental TKC 80 OEM tires ensure reliable traction right from the go. Functional, high quality components with plenty of well thought-out details easily withstand occasional ground contacts. The power plant, borrowed from the Duke 690 R, demonstrates a perfect throttle response and lots of power at any time, thanks to its sophisticated injection and “Electronic Power Trottle” (EPT) control. Simply a true Hard Enduro that goes along. Wherever.







2012 KTM 690 Enduro R Features and Benefits

– Dynamic LC4 1-cylinder 4-stroke engine, electronic fuel injection, balancer shaft, A PTC anti hopping clutch, 6-speed gearbox,
max. output: 49 kW/67 PS, emissions: Euro 3

– Stainless steel exhaust with catalytic converter

– Ultra-light steel trellis frame, self-supporting plastic tail tank

– New, more comfortable seat with enhanced ergonomics

– New adjustable WP suspension with revised spring rate, optimised front/rear weight distribution and agility

– High quality Brembo braking system

– Extremely low weight of 138 kg

– Sporty 21“/18“ Continental TKC 80 tires perfect for off-road riding

– New, more dynamic spoiler line

ENGINE SINGLE CYLINDER, 4-STROKE ENGINE · DISPLACEMENT 690 CC
STARTER ELECTRIC STARTER · TRANSMISSION 6 GEARS · TANK CAPACITY APPROX. 12L
WEIGHT (READY TO RACE) APPROX. 138.5 KG (WITHOUT FUEL)








2012 KTM 690 Enduro R – International Specifications/Technical Details
MSRP Price: See KTM dealer for pricing.

ENGINE

Displacement
Bore/stroke
Power
Torque
Compression ratio
Starter/battery
Transmission
Fuel system
Control
Lubrication
Engine oil
Primary drive
Final drive
Cooling
Clutch
Engine management/ignition

CHASSIS

Frame
Subframe
Handlebar
Front suspension
Rear suspension
Suspension travel front/rear
Font brake
Rear brake
ABS
Wheels front/rear
Tires front/rear
Chain
Silencer
Steering head angle
Trail
Wheel base
Ground clearance
Seat height
Tank capacity
Weight (ready to race)



Single cylinder, 4-stroke
690 cc, 102/84,5 mm
49 kW @ 7500 rpm
68 Nm @ 6000 rpm
12,5:1
Electric starter/12V 8.6Ah
6 gears
Keihin EFI with EPT (Electr. Power Throttle)
4 V/OHC with roller rocker levers
Pressure lubrication with 2 oil pumps
Motorex, SAE 10W-60
36:79
15:45
Liquid cooling
APTC slipper clutch, hydraulically operated
Keihin EMS



Chromium-Molybdenum trellis frame, powder coated
Self-supporting plastic tank
Aluminium, tapered, Ø 28/22 mm
WP-USD Ø 48 mm
WP-Monoshock with Pro-Lever linkage
250/250 mm
Brembo two piston floating caliper, brake disc Ø 300 mm
Brembo single piston, floating caliper, brake disc Ø 240 mm

Spoked wheels with aluminiumrims, 1,85 x 21″; 2,50 x 18″
90/90-21″; 140/80-18″
X-Ring 5/8 x 1/4″
Stainless steel silencer with regulated catalytic converter
63°
112 mm
1504 +/- 15 mm
280 mm
910 mm
approx. 12 litres/2.5 litres reserve
138,5 kg








2012 KTM 690 Enduro R – American Specifications/Technical Details
US MSRP Price: See KTM dealer for pricing and availability

To be annouced. See International Specifications.






2012 KTM 690 Enduro R – Canada Specifications/Technical Details
Canadian MSRP Price: See KTM dealer for pricing and availability

To be annouced. See International Specifications.
