Rugged and reliable 500cc powertrain, liquid cooled for consistent and optimal performance in all riding situations.
Review – Key Features – Features & Benefits – Specifications
2025 Harley-Davidson X500: AFFORDABLE. LIGHT AND FUN.
Introducing the 2025 Harley-Davidson X500…
Travel quickly and gallop freely, and the city is under the two wheels.
2025 Harley-Davidson X500 Totalmotorcycle.com Key Features
- upright riding position
- Center foot controls
- Passenger seat
- Safe Riding Enhancements
- Liquid-cooled, strong and reliable 500cc engine
- Pure American street car shape
- Easy-to-handle chassis, suspension and tires for confident driving from start to finish
2025 Harley-Davidson X500 Totalmotorcycle.com Features and Benefits
Engine
Rugged and reliable 500cc powertrain, liquid cooled for consistent and optimal performance in all riding situations.
Seat
Seat width and pad thickness are designed to enhance comfort on longer rides.
American Roadster Styling
Inspired by design cues from Harley-Davidson Sportster™ models
Real-world street-riding performance
Lightweight and agile, with an engine tuned for strong mid-range torque.
Riding ergonomics
Mid foot controls and a mid-rise handlebar puts the rider in a centered, comfortable posture on the bike.
Sound of Pleasure
2-into-1 exhaust designed to produce a pleasing low-frequency tone.
2025 Harley-Davidson X500 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $NA USD
Canada MSRP Price: $NA CDN
Europe/UK MSRP Price: £NA GBP (On The Road inc 20% Vat)
Australia MSRP Price: $ See Dealer AUD
NA
2025 Harley-Davidson X500 – Totalmotorcycle.com Canada Specifications/Technical Details
NA
2025 Harley-Davidson X500 – Totalmotorcycle.com Australia Specifications/Technical Details
Dimensions
Length
2,135 mm
Seat Height, Unladen
153 mm
Seat Height, Unladen
153 mm
Ground Clearance
24.5
Rake
100.4 mm
Trail
1,485 mm
Wheelbase
Maxxis Supermaxx ST
Tyres, Type
120/70-ZR17/58W
Tyres, Front Specification
160/60-ZR17/69W
Tyres, Rear Specification
13.1 l
Fuel Capacity
3.2 l
Oil Capacity (w/filter)
199 kg
Weight, In Running Order
208 kg
Engine
Engine+
Liquid-cooled, Parallel-Twin, 500cc
Bore
69 mm
Stroke
66.8 mm
Displacement
500 cc
Compression Ratio
11.5:1
Fuel System+
Electronic Sequential Port Fuel Injection (ESPFI)
Exhaust
2 into 1 short single, 3 catalyst
Performance
Engine Torque Testing Method
GB/T20076-2006, GB/T5363-2008
Engine Torque+
46 Nm
Engine Torque (rpm)
6000
Horsepower
47 HP / 35 kW @ 8500 rpm
Lean Angle, Right (deg.)
46.9
Lean Angle, Left (deg.)
49.5
Fuel Economy Testing Method
WMTC
Fuel Economy+
4.85 l/100 km
CO2 Emissions Testing Method
WMTC
CO2 Emissions
112 g/km CO2
Drive Train
Primary Drive
Chain, 74/38
Gear Ratios (overall) 1st
2.85
Gear Ratios (overall) 2nd
1.95
Gear Ratios (overall) 3rd
1.56
Gear Ratios (overall) 4th
1.33
Gear Ratios (overall) 5th
1.19
Gear Ratios (overall) 6th
1.08
Chassis
Front Fork
50mm upside down rebound adjustable
Rear Shocks
Oil and gas separation type, rebound damping adjustable, preload adjustable shock absorber
Wheels, Front Type+
Cast aluminium
Wheels, Rear Type+
Cast aluminium
Brakes, Caliper Type
Front floating, rear solid
Brakes, Rotor Type
4-piston fixed front and 1-piston floating rear
Electric
Lights (as per country regulation), Headlamp, Tail/Stop/Front Signal Lights
All LED, low beam, high beam and signature position lamp. All LED Tail/Stop, front signal lights and rear turn signals.
Gauges
Combined electronic instrument stepper motor indicating vehicle speed, digital indicates rpm, hour, total trip, two trips (A + B), km/mile indication
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
