2024 Yamaha YZ85: VICTORY: NEVER GIVEN, ALWAYS EARNED.
Introducing the new 2024 Yamaha YZ85…
Built for fun. Built to win. The renowned YZ85 serves up big‑bike specs in a small‑bike package.
Built for fun. Built to win. The YZ85 serves up big-bike specs in a small-bike package. Boasting many premium features to earn its stripes in the YZ lineup, the YZ85 is ready to win races straight off the dealership floor.
Yamaha has been building championship winning 2-stroke motocross bikes for 50 years. Along the way we’ve won just about every title worth winning. The latest YZ85 comes with the same advanced race-bred technology that goes into the company’s adult motocross machines, and is ready to power you into the victorYZone.
Many of today’s pro riders started their careers on the YZ85. And when you take a look at what this bike has to offer you can see why. Its high performance 85cc liquid-cooled 2-stroke engine is equipped with Yamaha’s race-bred YPVS that gives you holeshot-winning acceleration. And its adjustable suspension systems are built to master the toughest tracks.
The YZ85 also comes with a lightweight aluminium rear frame and aluminium swingarm, large diameter disc brakes and a high-efficiency air intake – just like the bigger YZ125. For maximum rider control there’s a flat seat, slim body, and an ergonomic fuel tank. And with a duo-tone Icon Blue color scheme and new graphics completing the looks, the YZ85 is ready to power you to the next level.
YPVS™ Two-Stroke Power
The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System (YPVS™) for increased low- and mid-range power without losing peak power at high rpms, reducing the need for frequent shifting.
FULLY-ADJUSTABLE SUSPENSION
Lightweight 36mm KYB® inverted cartridge fork features low-friction outer tubes, external compression and rebound damping adjustability, paired with a race-proven fully-adjustable KYB® rear shock. Both offer loads of suspension travel to tackle serious off-road competition.
HIGH-SPEC WHEELS & BRAKES
Stylish blue, lightweight 17-inch front and 14-inch rear rims are durable, reduce unsprung weight for optimal suspension performance, and come wrapped in Dunlop® MX3S tires for exceptional traction. Big 220mm and 190mm disc brakes offer precise control and outstanding stopping power.
2024 Yamaha YZ85 Totalmotorcycle.com Key Features
- Optimized Air Intake Design
- Yamaha Power Valve System (YPVS) for broad, tractable power
- Potent, easy-to-service two-stroke engine
- Smooth-shifting, six-speed, close-ratio transmission
- Compact, semi-double-cradle, single-backbone steel frame
- Race-ready, fully adjustable suspension
- Aggressive YZ styling
The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System for broad power across the rev range without losing peak power at high rpms—improving rideability and reducing the need for frequent shifting.
Inspired by its YZ125 sibling, the aggressive graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance.
2024 Yamaha YZ85 Totalmotorcycle.com Features and Benefits
TOP FEATURES
Fully-Adjustable Suspension
Lightweight 36mm KYB® inverted cartridge fork features low-friction outer tubes, external compression and rebound damping adjustability, paired with a race-proven fully-adjustable KYB® rear shock. Both offer loads of suspension travel to tackle serious off-road competition.
High-Quality Embedded Graphics
Inspired by its YZ125 sibling, the aggressive graphics scheme highlights the YZ’s unmatched racing pedigree. Premium Yamaha Blue and dark blue graphics are embedded to provide excellent durability and scratch resistance.
High-Spec Wheels & Brakes
Stylish blue, lightweight 17-inch front and 14-inch rear rims are durable, reduce unsprung weight for optimal suspension performance, and come wrapped in Dunlop® MX3S tires for exceptional traction. Big 220mm and 190mm disc brakes offer precise control and outstanding stopping power.
Optimized Chassis Design
Built for demanding junior racers, the YZ85’s chassis is optimized for strength, rigidity and overall handling stability. The aluminum swingarm offers refined balance between longitudinal and torsional rigidity, and the removable rear subframe constructed from lightweight, high-strength aluminum reduces weight.
Performance-Minded Ergonomics
The flat seat and narrow fuel tank design, along with smoothly integrated body panels and slim shroud width, combine to enable greater freedom of movement forward and back, allowing the rider to easily shift body weight for increased control and confidence.
YPVS™ Two-Stroke Power
The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System (YPVS™) for increased low- and mid-range power without losing peak power at high rpms, reducing the need for frequent shifting.
ADDITIONAL FEATURES
Adjustable Rider Ergonomics
The four-position adjustable handlebar mounts and taper-style handlebar allow the rider to tune the handlebar position to suit their size and preferences. Flat seat and narrow fuel tank design, along with smoothly integrated body panels and slim shroud width, combine to enable greater freedom of movement for increased control and confidence.
CHASSIS/SUSPENSION
Fully-Adjustable Fork
The lightweight 36mm KYB® inverted cartridge fork features 10.8 inches of travel with compression and rebound damping adjustability. Complete with low-friction outer tubes and internals, the damping settings offer enhanced performance across a range of conditions and rider abilities.
Fully-Adjustable Shock
Rear suspension features fully adjustable KYB® link-type shock with race-tested valving and 11.1 inches of travel. The progressive linkage-type design improves bottoming resistance, allowing racers to charge harder and improve lap times.
High Performance Tires
Dunlop® MX3S tires provide exceptional traction on a variety of tracks and terrain.
Large-Diameter Brakes
Big wave-style brake discs offer improved self-cleaning and cooler-running performance. The 220mm front disc and 190mm rear disc deliver strong, precise stopping power. Rear brake master cylinder also includes built-in sub-reservoir to provide more linear brake response and increased control.
Lightweight Wheels
Lightweight 17-inch front and 14-inch rear rims are durable and reduce unsprung weight for optimal suspension performance.
Optimized Chassis Design
Built for demanding junior racers, the YZ85’s chassis is optimized for strength, rigidity and overall handling stability. The aluminum swingarm offers refined balance between longitudinal and torsional rigidity, and the removable rear subframe constructed from lightweight, high-strength aluminum reduces weight.
ENGINE
Advanced Intake Design & High-Flow Airbox
Advanced intake design allows for a straighter, more efficient draw of air into the intake tract. High-flow airbox ensures excellent air filter performance and easy maintenance.
Durable Transmission
The transmission features oversized gears to provide enhanced engagement and smoother shifts.
High Capacity Radiator
Lightweight radiator has large cores and louvers. Water pump features a cast aluminum (vs. resin) impeller for maximum cooling efficiency.
Potent YPVS™ Two-Stroke Engine
The 85cc liquid-cooled, two-stroke engine features the Yamaha Power Valve System (YPVS™) for broad power across the rev range without losing peak power at high rpms, reducing the need for frequent shifting.
Tuned Crankcase & Intake
The crankcase design features a spacer-style reed valve intake for improved air/fuel flow, which inhales through a 28mm Hitachi Astemo® Keihin flat-slide carburetor for seamless throttle response.
Tuned Expansion Chamber
Carefully matched to suit the YPVS™-equipped engine, the exhaust expansion chamber optimizes gas flow for enhanced power delivery, especially in the low- and mid-range.
*Manufacturer’s Suggested Retail Price (MSRP) shown. Does not include tax, title, prep or destination charges. Actual prices set by dealer.
**Fuel Economy is estimated.
***Wet weight includes the vehicle with all standard equipment and all fluids, including oil, coolant (as applicable) and a full tank of fuel. It does not include the weight of options or accessories. Wet weight is useful in making real-world comparisons with other models.
2024 Yamaha YZ85 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $4,999 USD
Canada MSRP Price: $6,599 CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)
- Engine
Engine type
Liquid-cooled, Single cylinder, Reed valve with YPVS, 2-stroke
Displacement
85cc
Bore x stroke
47.5 × 47.8 mm
Compression ratio
8,2 – 9,6 : 1
Lubrication system
Premix
Clutch type
Wet, Multiple Disc
Ignition system
CDI
Starter system
Kick
Transmission system
Constant Mesh, 6-speed
Final transmission
Chain
Fuel system
Keihin PWK28/1
- Chassis
Frame
Semi double cradle
Caster angle
26° 00
Trail
99 mm
Front suspension system
Telescopic fork
Rear suspension system
Swingarm, (Link type suspension)
Front travel
275 mm
Rear travel
287 mm
Front brake
Hydraulic Single Disc, Ø220 mm
Rear brake
Hydraulic Single Disc, Ø190 mm
Front tyre
70/100-19 42M Tube type
Rear tyre
90/100-16 52M Tube type
- Dimensions
Overall length
1895 mm
Overall width
760 mm
Overall height
1175 mm
Seat height
885 mm
Wheel base
1285 mm
Minimum ground clearance
360 mm
Wet weight (including full oil and fuel tank)
75 kg
Fuel tank capacity
5.0 L
Oil tank capacity
0.5 L
2024 Yamaha YZ85 – Totalmotorcycle.com Canada Specifications/Technical Details
- Engine
Engine type
Liquid-cooled, Single cylinder, Reed valve with YPVS, 2-stroke
Displacement
85cc
Bore x stroke
47.5 × 47.8 mm
Compression ratio
8,2 – 9,6 : 1
Lubrication system
Premix
Clutch type
Wet, Multiple Disc
Ignition system
CDI
Starter system
Kick
Transmission system
Constant Mesh, 6-speed
Final transmission
Chain
Fuel system
Keihin PWK28/1
- Chassis
Frame
Semi double cradle
Caster angle
26° 00
Trail
99 mm
Front suspension system
Telescopic fork
Rear suspension system
Swingarm, (Link type suspension)
Front travel
275 mm
Rear travel
287 mm
Front brake
Hydraulic Single Disc, Ø220 mm
Rear brake
Hydraulic Single Disc, Ø190 mm
Front tyre
70/100-19 42M Tube type
Rear tyre
90/100-16 52M Tube type
- Dimensions
Overall length
1895 mm
Overall width
760 mm
Overall height
1175 mm
Seat height
885 mm
Wheel base
1285 mm
Minimum ground clearance
360 mm
Wet weight (including full oil and fuel tank)
75 kg
Fuel tank capacity
5.0 L
Oil tank capacity
0.5 L
2024 Yamaha YZ85 – Totalmotorcycle.com European Specifications/Technical Details
- Engine
Engine type
Liquid-cooled, Single cylinder, Reed valve with YPVS, 2-stroke
Displacement
85cc
Bore x stroke
47.5 × 47.8 mm
Compression ratio
8,2 – 9,6 : 1
Lubrication system
Premix
Clutch type
Wet, Multiple Disc
Ignition system
CDI
Starter system
Kick
Transmission system
Constant Mesh, 6-speed
Final transmission
Chain
Fuel system
Keihin PWK28/1
- Chassis
Frame
Semi double cradle
Caster angle
26° 00
Trail
99 mm
Front suspension system
Telescopic fork
Rear suspension system
Swingarm, (Link type suspension)
Front travel
275 mm
Rear travel
287 mm
Front brake
Hydraulic Single Disc, Ø220 mm
Rear brake
Hydraulic Single Disc, Ø190 mm
Front tyre
70/100-19 42M Tube type
Rear tyre
90/100-16 52M Tube type
- Dimensions
Overall length
1895 mm
Overall width
760 mm
Overall height
1175 mm
Seat height
885 mm
Wheel base
1285 mm
Minimum ground clearance
360 mm
Wet weight (including full oil and fuel tank)
75 kg
Fuel tank capacity
5.0 L
Oil tank capacity
0.5 L
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
