2024 KTM 790 Adventure Guide

2024 KTM 790 Adventure
ReviewKey FeaturesFeatures & BenefitsSpecifications

2024 KTM 790 Adventure 2024 KTM 790 Adventure 2024 KTM 790 Adventure 2024 KTM 790 Adventure 2024 KTM 790 Adventure

2024 KTM 790 Adventure: CHASE THE HORIZON.

Introducing the 2024 KTM 790 Adventure…

The 2024 KTM 790 ADVENTURE is designed to make 2-wheeled adventure travel easier. Capable, comfortable, and cost-effective, it not only ticks all the boxes of what an adventure machine should be. instead, it breaks out of the box altogether. Built around a torquey parallel twin-cylinder powerplant, and boasting a class-leading electronics package, it’s the perfect choice for riders looking to chase the horizon.







2024 KTM 790 Adventure Totalmotorcycle.com Key Features

ADVENTURE FOR EVERYONE







2024 KTM 790 Adventure Totalmotorcycle.com Features and Benefits

Hit the street

KEEEPING YOU MOVING

Rider aids

KTM rider aids are developed to enhance the overall ADVENTURE experience by providing more control in different riding scenarios. ABS, MTC, and specially engineered RIDE MODES allow you to get the most out of your machine when barreling down the tarmac on your way to the rough stuff.

UNMATCHED TRACTION

MTC (Motorcycle Traction Control)

Making use of the latest generation of KTM MTC, traction is improved by using an advanced 6D Inertial Measurement Unit. This not only regulates and controls any slip at the rear wheel but also prevents uncontrolled lifting of the front wheel. With these two forces combined, the motorcycle is guaranteed the best possible acceleration. And when further combined with the data collected from the lean angle sensor, the system detects and controls power wheelies and ensures stability as well as smooth wheel landing and acceleration.

FULL CONFIDENCE IN THE CORNERS

Cornering ABS

Grab a handful of brakes with total confidence thanks to a new 9.3 MP ABS unit. This allows riders to use full braking power mid-corner with the 6D-sensor doing all the hard work. The 6D-sensor works by continuously monitoring and evaluating the current dynamic state of the motorcycle, enhancing safety and stability during braking. Also, this level of ABS technology is unmatched, providing precise and efficient stopping power with the highest level of safety.

RIDE ALL DAY

Seat Comfort

The two-piece seat on the KTM 790 ADVENTURE is developed with rider and pillion comfort in mind. For more adventurous offroading, a single-piece Rally seat is available along with other seat options in the KTM PowerParts catalog.

On the dirt

DOMINATE THE DIRT

Offroad ABS

For the 2024 KTM 790 ADVENTURE, Offroad ABS is automatically toggled when you’ve selected Offroad or optional Rally Mode. This means ABS functionality is reduced on the front wheel, and completely deactivated on the rear, allowing riders to slide the back-end into a corner. Simply put – more braking power and control in the dirt when you need it, with the ability to shred the trail when you don’t.

READY TO SHRED

Tires

The 2023 KTM 890 ADVENTURE R is fitted with all-new MITAS ENDURO TRAIL rubber, specifically optimized for KTM. These are ideal for riders looking for durability, handling, and mileage on road, but with the added benefit of being able to conquer difficult offroad tracks and trails with ease.

TUNED TO TRAVEL

Reworked Suspension

Upfront, the 43 mm WP APEX open cartridge upside-down front fork has been specifically set up for adventure riding. Split function technology separates the compression and rebound damping between the two fork legs, with suspension travel set to 200 mm. On the rear, a WP APEX shock absorber keeps the ride smooth and balances typical KTM performance riding with all-day riding comfort.

Behind the bars

RALLY INSPIRED

Bodywork

A completely reworked and striking front end gives the KTM 790 ADVENTURE true READY TO RACE looks. In addition, the structure below the fairing makes use of 2 forged aluminum brackets that provide maximum stiffness to the front mask, windshield, and instrument tower. This, along with using in-mold graphics for durability and a low front fender designed to keep unwanted water and mud spray to a minimum, makes the KTM 790 ADVENTURE ready for any adventure.

ADVENTURE READY

CTG

For 2024, the KTM 790 ADVENTURE is undeniably READY TO RACE with two new color ways, an all-new white with orange graphics and a black option. The graphics are produced with in-mold technology instead of stickers raising the level of finish and durability.

PLAIN SAILING

Aerodynamics

The 2024 KTM 790 ADVENTURE sports a KTM Rally-inspired, taller windscreen for improved wind protection on road, with unique anti-buffer aerodynamics.

COMMAND CONTROL

Upgraded TFT Display

A state-of-the-art full 5″ TFT display keeps you informed with everything you need to know about the machine below you. Featuring improved functionality, each function is illustrated by an infographic of the motorcycle to directly show the user the relevant field of adjustment. An optically bonded mineral glass display ensures optimum scratch and glare resistance. Additionally, an optional Connectivity Unit allows the connection between the KTMconnect app and the TFT via Bluetooth for Turn-by-Turn+ navigation, music, incoming calls, and quick access to KTM roadside assistance.

FREEDOM OF MOVEMENT

Ergonomics

With tank spoilers and rear side panels slightly wider than the seat, hitting the long road to nowhere is easier thanks to improved rider movement. This also helps with reduced wear and tear on the seat, while the slim shape of the fuel tank is optimized for precise handling and control when standing on the pegs.

TECH FEST

Technology

The 2023 KTM 790 ADVENTURE brings unmatched technology to the trail. Boasting an arsenal of rider aids, ride modes, ABS and traction control features – as well as smartphone connectivity – it rules the mid-weight adventure bike roost. The riding experience can be further enhanced with optional additions like Quickshifter+ and Cruise Control, with the introduction of a Demo Mode, that allows you to test the tech on the first 1.500km.



On the ride

READY TO RACE

Engine

The 2024 KTM 790 ADVENTURE is powered by an improved EURO5 790 cc parallel-twin compared to its predecessor. A reworked clutch with better lubrication and new clutch discs makes for smoother shifting, while a 20% increase in crankshaft weight helps smoothen the ride even more. An additional knocking control system also means fewer worries when filling up with poorer grade fuel in far away places.

ENGINEERED TO RIDE

Frame

The overall geometry of the KTM 790 ADVENTURE was developed for light handling, and comfort on long-distance exploration missions – with unchallenged offroad capability. Strength was a big consideration in the design, so a tubular Chromoly steel frame is used with the engine acting as a stressed member to reduce weight and overall size. An all-new engine protector also adds a little more piece of mind when out of the trail. All design and engineering innovations are focused on being compact and light.

FULLY-LOADED

Subframe

Featuring a lightweight and solid construction, the subframe is fully-loaded for adventure. The motorcycle beneath you needs to be built to last. The steel trellis subframe was developed to be compact, lightweight and also strong enough to carry a full load of luggage as well as a passenger under the hardest conditions while extreme adventure riding.

ROCK SOLID

Stability

The 2024 KTM 790 ADVENTURE is rock solid at any speed, thanks to a high-end steering damper. Engineered to provide unflappable composure at all times, the steering damper works to keep the front end stable when flicking through tight turns, or hauling over corrugated surfaces.









2024 KTM 790 Adventure – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ See Dealer for pricing in USD
Canada MSRP Price: $ See Dealer for Pricing CDN
Europe/UK MSRP Price: £ See Dealer for pricing in GBP (On The Road inc 20% Vat)

Engine
Torque 87Nm
Transmission 6-speed
Cooling Liquid cooled
Power in KW 70kW
Starter Electric starter
Stroke 65.7mm
Bore 88mm
Clutch PASC™ antihopping clutch, mechanically operated
Displacement 799cm³
EMS Bosch EMS with RBW
Design 2-cylinder, 4-stroke, parallel twin
Fuel consumption 4.2l/100 km
Lubrication Forced oil lubrication with 2 oil pumps



Chassis
Tank capacity (approx.) 20l
ABS Bosch 9.3 MP (incl. Cornering-ABS and off-road mode, disengageable)
Front brake disc diameter 320mm
Rear brake disc diameter 260mm
Front brake 2x radially mounted 4 piston caliper
Rear brake 2 piston floating caliper
Chain 520 X-Ring
dry weight 199kg
Frame design Chromium-Molybdenum-Steel frame using the engine as stressed element, powder coated
Front suspension WP APEX 43
Ground clearance 233mm
Rear suspension WP APEX – Monoshock
Seat height 860/840 mm
Steering head angle 64.1°
Suspension travel (front) 200mm
Suspension travel (rear) 200mm



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
