2023 Kawasaki Ninja H2: AWE-INSPIRING, SUPERCHARGED POWER.

Introducing the 2023 Kawasaki Ninja H2…

The Ninja H2 and Ninja H2 Carbon motorcycles bring the mind-bending power of Kawasaki’s supercharged hypersport racer to the street. Boasting a powerful 998cc inline four-cylinder engine, state-of-the-art electronics, and the latest Brembo brakes, the Ninja H2 and Ninja H2 Carbon amount to pure performance on the road.

The Ninja H2 and Ninja H2 Carbon motorcycles amount to pure street-legal hypersport.

Performance. Featuring a 998cc inline four-cylinder engine, proprietary supercharger, lightweight trellis frame, compact superbike dimensions, aerodynamic bodywork, and a rigid single-sided swingarm. Both models feature high-spec Brembo Stylema brake calipers, Kawasaki Quick Shifter (KQS), Kawasaki TRaction Control (KTRC-9 modes) and Kawasaki’s highly durable self-healing paint. In the cockpit, a TFT (thin-film transistor) color instrumentation display with four selectable display modes can be found, as well as Bluetooth Smartphone Connectivity via RIDEOLOGY THE APP*. Bringing all this power and technology to the pavement are Bridgestone RS11 tires. The Ninja H2 Carbon was developed as a special, limited-edition model that features beautiful, strong, and lightweight carbon fiber front bodywork and special insignia.





2023 Kawasaki Ninja H2 Totalmotorcycle.com Key Features

  • Street legal hypersport performance
  • Bosch IMU with Kawasaki’s dynamic modeling software
  • KYB AOS-II front fork and Öhlins TTX36 rear shock
  • Kawasaki Quick Shifter (KQS)
  • Kawasaki TRaction Control (KTRC–9 modes)
  • Kawasaki Intelligent anti-lock Brake System (KIBS)
  • Kawasaki Launch Control Mode (KLCM)
  • Kawasaki Engine Brake Control (KEBC)
  • All LED lighting
  • Bridgestone Battlax RS11 sport tires
  • Smartphone Connectivity via RIDEOLOGY THE APP
  • All-Digital TFT color intstrumentation





2023 Kawasaki Ninja H2 Totalmotorcycle.com Features and Benefits

SUPERCHARGED POWER UNPRECEDENTED POWER
The Ninja H2 streetbike’s supercharged engine creates unprecedented power for remarkable acceleration. The heavy growl of the boosted liter-class engine is a sound the streets won’t soon forget.

IN-HOUSE DESIGNED
Chosen for its high-rpm performance, the centrifugal-type supercharger is incredibly efficient at compressing air (at up to 2.4x atmospheric pressure) while minimizing heat. As a result of the supercharger’s efficiency, no large, heavy intercooler is required to cool the compressed air. The supercharger was designed to match the engine, allowing high-efficiency operation over a wider range of conditions that could not be provided by a typical supercharger.

HIGH-PERFORMANCE COMPONENT
The complex shape of the impeller is 3D machined from forged aluminum for high precision and durability. The impeller spins at 9.2x speed of the crankshaft, reaching speeds of nearly 130,000 rpm, pumping a capacity of over 200 liters of air per second into the engine.

COMPACT & EFFICIENT
Designed using technology from Kawasaki Heavy Industries., Ltd. (KHI) Aerospace Company, the planetary gear transfers power from the crankshaft to drive the impeller to incredibly high rpm.

UNMATCHED POWER
The balanced supercharged engine delivers both exhilarating acceleration and superb fuel efficiency. The key to achieving this balance was increasing the engine’s thermal efficiency by utilizing a high compression ratio. Designed for high-performance racing engines, the premium dog-ring transmission allows for smooth, precise, quick shifting. Rather than shifting gears into place, the gears in this configuration stay in place, with the lightweight dog rings moving to engage the gears. A high-quality hydraulic Assist and Slipper clutch minimizes wheel chatter caused by rapid downshifting and self-adjusts to ensure consistent performance and smooth actuation.

PERFORMANCE
UNPARALLELED IN EVERY WAY
The massive power of the supercharged engine necessitates a multitude of high-performance components to ensure an unforgettably effortless, yet forceful experience.

INNOVATIVE & INTELLIGENT
The Ninja H2 hypersport utilizes Kawasaki Intelligent anti-lock Brake System (KIBS) technology and comes equipped with dual radial-mount opposed four-piston Brembo Stylema front calipers and semi-floating 330mm discs for aggressive braking. The Brembo clutch and front brake levers were designed to prevent wind force from engaging the levers while at higher speed.

All trademarks, registered trademarks, logos, and copyrights are the property of their respective owners.

PERFORMANCE-INSPIRED
The lightweight cast aluminum wheels were designed specifically for the Ninja H2 and were created using analysis from Kawasaki’s World Superbike team. Star-pattern 5-spoke wheels offer optimum rigidity for high-power performance and feature pinstripes for a prestigious image. Bridgestone Battlax RS11 sport tires contribute to sharp handling.

SMOOTH & PRECISE
The Öhlins TTX36 rear shock offers precise damping for enhanced traction, comfort and feedback to the rider. The KYB AOS-II (Air-Oil-Separate) low friction cartridge fork offers superb action; initial stroke is smooth and compliant followed by progressive damping through the end of the stroke. The front fork is fully adjustable for compression and rebound damping, as well as preload.

ADVANCED ELECTRONICS
STATE-OF-THE-ART
Key enhancements bring Kawasaki Racing Team (KRT) WorldSBK championship-proven electronics management technology to the Ninja H2 motorcycle. This results in precise chassis orientation awareness that assists the rider’s ability to adapt to a wide range of typical street riding conditions and scenarios.

KAWASAKI ENGINE BRAKE CONTROL
This system allows riders to set engine braking according to preference. When the system is activated, the engine braking effect is reduced, providing less interference when riding on the circuit.

KAWASAKI QUICK SHIFTER
Complementing the engine’s strong power and the dog-ring transmission, a contactless-type quick shifter enables quick upshifts for seamless acceleration. The KQS enables clutchless downshifts for quick and smooth deceleration.

TAKE CONTROL FROM YOUR PHONE
Bluetooth Smartphone Connectivity (using RIDEOLOGY THE APP*) connects you with your bike like never before, allowing you to view vehicle info, riding log, phone notifications, and general settings.

*RIDEOLOGY THE APP is not intended for use during vehicle operation. Only use RIDEOLOGY THE APP when the vehicle is not being operated and it is safe to do so.

OPTIMAL LAUNCH
Three-mode Kawasaki Launch Control Mode (KLCM) provides unmatchable acceleration from a stop by electronically controlling engine output to minimize rear wheel-slip and front end lift. KLCM allows the rider to launch from a stop with the throttle held wide open.

PREDICTIVE & ADAPTIVE
The Bosch Inertial Measurement Unit (IMU) enables inertia along 6 Degrees of Freedom to be monitored. This next-level system enables predictive and adaptive electronics for precise chassis orientation awareness.

STYLING
STUNNING & ICONIC
The Ninja H2 motorcycle design projects intense force becoming a product of functional beauty. Each and every angle is designed to contribute unprecedented performance and style.

INTUITIVE & INNOVATIVE
Designed by KHI Aerospace Company, the mirror stays feature airfoil cross-sections with Gurney flaps that contribute to downforce generation. A chin spoiler on the upper cowl is also function disguised in form, further contributing to downforce production.

STRENGTH & FLEXIBILITY
The trellis frame provides the strength to harness the incredible power of the supercharged engine and the balanced flex to achieve optimal rigidity and pliability for aggressive sport riding.

PREMIUM QUALITY
Features a special top coat on all non-carbon bodywork parts that allows certain types of scratches to repair themselves, enabling the paint to maintain its high-quality finish through normal wear and tear*. Self-healing is achieved through microscopic soft and hard segments within the top coat to work like a chemical spring that creates a trampoline effect to absorb impacts.

*Paint recovery is not immediate and may take more than one week. The paint will not recover from all scratches, including those caused by a coin, key, or zip fastener.

USEFUL INFORMATION AT A GLANCE
All-digital TFT (thin-film transistor) color instrumentation gives the cockpit a high-tech, high-grade appearance and visibility. The screen’s background color is selectable (black or white), and screen brightness adjusts automatically to suit available light.

Display functions include: digital speedometer, digital bar-style tachometer, gear position indicator, shift lamp, fuel gauge, odometer, dual trip meters, current and average fuel consumption, remaining range, average speed, total time, coolant temperature, clock, battery voltage, Kawasaki service reminder, oil change reminder and the Kawasaki Economical Riding Indicator.

LIGHT THE WAY
For a bright and more efficient look, all light equipment utilizes LED technology, including turn signals and license plate lamp.











2023 Kawasaki Ninja H2 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $31,500 USD
Canada MSRP Price: $37,500 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)

POWER
Engine Liquid -cooled, 4-stroke, In-Line Four, DOHC, 16-valve
Displacement 998cc
Bore x Stroke 76.0 x 55.0mm
Compression Ratio 8.5:1
Fuel System DFI® with 50mm throttle bodies (4) with dual
injection ; Kawasaki Supercharger
Ignition Digital
Transmission 6-speed, return, dog-ring
Final Drive Sealed chain
Electronic Rider
Aids
Kawasaki Cornering Management Function (KCMF),
Kawasaki TRaction Control (KTRC), Kawasaki Launch
Control Mode (KLCM), Kawasaki Intelligent anti-lock
Brake System (KIBS), Kawasaki Engine Brake Control,
Kawasaki Quick Shifter (KQS) (upshift & downshift),
Öhlins Electronic Steering Damper
Maximum Torque 104.9 lb-ft @ 11,000 rpm
PERFORMANCE
Front Suspension /
Wheel Travel
43mm inverted fork with adjustable rebound and
compression damping, spring preload adjustability
and top-out springs/4.7 in
Rear Suspension /
Wheel Travel
Uni-Trak®, Öhlins TTX36 gas charged shock with
piggyback reservoir, 24-way compression and
rebound damping and adjustability and hand-turn
spring preload adjustability, and top-outspring/5.3
in
Front Tire 120/70 ZR17 (58W)
Rear Tire 200/55 ZR17 (78W)
Front Brakes Dual radial-mount, opposed 4-piston Brembo
Stylema® calipers, dual semi-floating 330mm discs,
KIBS ABS
Rear Brakes Opposed 2-piston calipers, single 250mm disc, KIBS
ABS
DETAILS
Frame Type Trellis, high-tensile steel, with swingarm mounting
plate
Rake/Trail 24.5°/4.1 in
Overall Length 82.1 in
Overall Width 30.3 in
Overall Height 44.3 in
Ground Clearance 5.1 in
Seat Height 32.5 in
Curb Weight 524.8 lb*
Fuel Capacity 4.5 gal
Wheelbase 57.3 in
Special Features Rideology the App Smartphone Connectivity, all-LED
lighting, Highly Durable Paint, TFT Instrumentation
Color Choices Mirror Coated Spark Black
Warranty 12 Month Limited Warranty
Kawasaki
Protection Plus™
(optional)
12, 24, 36 or 48 months





2023 Kawasaki Ninja H2 – Totalmotorcycle.com  Canadian Specifications/Technical Details

POWER
Engine 998cc, liquid-cooled, 4-stroke, DOHC 16-valve in-line four
Bore x Stroke 76.0 x 55.0 mm
Compression Ratio 8.5:1
Fuel System Fuel injection: ø50 mm x 4 with dual injection
Intake System Kawasaki Supercharger
Ignition Digital
Starting Electric
Lubrication Forced lubrication, wet sump with oil cooler
Transmission 6-speed, return, dog-ring
Clutch Wet multi-disc, manual
Final Drive Chain

PERFORMANCE
Frame Trellis, high-tensile steel, with Swingarm Mounting Plate
Front Suspension / Wheel Travel ø43 mm inverted fork with rebound and compression damping, spring preload adjustability and top-out springs / 120 mm (4.7 in)
Rear Suspension / Wheel Travel New Uni Trak, Öhlins TTX36 gas-charged shock with piggyback reservoir, compression and rebound damping and spring preload adjustability, and top-out spring / 135 mm (5.3 in)
Rake / Trail 24.5° / 103 mm
Steering Angle (L/R) 27° / 27°
Front Tire 120/70ZR17M/C (58W)
Rear Tire 200/55ZR17M/C (78W)
Front Brakes Dual semi-floating ø330 mm Brembo discs with radial-mount, Brembo Stylema monobloc, opposed 4-piston calipers
Rear Brake ø250 mm disc with Brembo, opposed 2-piston caliper

DETAILS
Dimensions (L x W x H) 2,085 x 770 x 1,125 mm (82.1 x 30.3 x 44.3 in)
Wheelbase 1,455 mm (57.3 in)
Road Clearance 130 mm (5.1 in)
Seat Height 825 mm (32.5 in)
Curb Mass** 238 kg (525 lb)
Fuel Capacity 17 litres
Instrumentation Analogue-style tachometer + full-colour TFT screen with digital speedometer, gear position indicator, odometer, dual trip meters, current mileage, average mileage, fuel consumption, bank angle display and max bank angle recording function, average speed, total time, coolant temperature, boost indicator, boost (intake air chamber) temperature, clock, and Economical Riding Indicator
Warranty 12 months
Kawasaki Protection Plus 12 / 24 / 36 / 48 months





2023 Kawasaki Ninja H2 – Totalmotorcycle.com European Specifications/Technical Details

NA





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
