2023 Husqvarna FX450: RIDE SMOOTHLY TOWARDS VICTORY.

Introducing the 2023 Husqvarna FX450…

Benefitting from multiple technical upgrades for 2023, the FX 450 retains its class-leading on-track performance and continues to headline the Husqvarna Motorcycles off-road line-up. With an all-new engine that not only produces a broad spread of usable power, but also positions the engine shaft arrangements at the ideal centre of gravity to centralise mass, accentuating the lightweight feel of the FX 450. Aiding this agile feel is the new chassis which has been developed and manufactured using advanced engineering techniques to offer improved anti-squat behavior for enhanced handling and maneuverability. Retaining the advanced electronics and high-quality components throughout, the FX 450 is complete with a new flatter seat and finished with functional bodywork adorned with white, yellow, and grey graphics inspired by the Swedish heritage of the brand.







2023 Husqvarna FX450 Totalmotorcycle.com Key Features

What is new for 2023:

  • New bodywork with specifically tailored ergonomics for easier movement on the motorcycle
  • New hydro-formed chromium-molybdenum frames significantly improve anti-squat behavior
  • New topology-optimized die-cast aluminum swingarm provides optimal rigidity and low weight
  • New throttle body fuel injection on 2-stroke engines ensures class-leading power and rideability
  • New FC/FX 250 and FC/FX 350 DOHC engines deliver class-leading torque and peak power
  • New Quickshift sensor ensures seamless upshifting on all FC 4-stroke models and the cross-country FX 450
  • New electric start on all 2-stroke models
  • New aluminum-polyamide hybrid subframe construction provides specifically calculated rigidity and advanced durability
  • New WP XACT 48 mm front forks with AER technology offer more progressive end-of-stroke damping
  • New WP XACT rear shock design with CFD-optimized main piston and tool-free adjusters
  • New multifunctional Map Select Switch also activates the Quickshifter, Traction, and Launch Control on select models
  • High-performance Brembo hydraulic clutch system
  • Premium-quality ProTaper handlebars
  • Electric start powered by a lightweight Li-Ion 2.0 Ah battery



USQVARNA MOTORCYCLES UNVEILS ITS NEW GENERATION OF MOTOCROSS AND CROSS-COUNTRY MACHINERY
DESIGNED FROM THE GROUND UP WITH INNOVATIVE ENGINEERING TECHNIQUES THE FC AND TC MOTOCROSS AND FX AND TX CROSS-COUNTRY MODELS CONTINUE TO OUTPERFORM THE COMPETITION

Continuing to deliver true motocross performance, the all-new 2023 Husqvarna Motorcycles TC and FC models further enhance the on-track riding experiences of all riders. Highly capable of competing at the top levels of racing as standard, technical advancements across the five-motorcycle-strong range include new engines, suspension, frames, swingarms, and bodywork. Each of the 2-stroke and 4-stroke machines receive tailored developments for maximum performance.

Taking charge in the off-road segment is the all-new, technologically advanced cross-country TX and FX models, which share the innovative platforms found on the 2023 motocross range. With off-road suited features such as large capacity fuel tanks, cross-country specific settings in the WP XACT suspension, convenient, newly designed side stands and a 21/18-inch D.I.D DirtStar wheel set fitted with Dunlop MX33 fronts and AT81 rears, this new generation of TX and FX machines is ready to take off-road riding and racing to the next level of performance and control.

Strengthening their positions as the leading 2-strokes on the market, the TC 125 and TC 250 are now equipped with Electronic Fuel Injection (EFI) and E-Start as standard. The throttle body fuel injection system ensures class-leading power and rideability, as well as enhancing reliability, and lowering overall running costs. Both machines are now easily started with the simple press of a button. These significant enhancements underline the continued evolution of these popular models, which set the benchmark for premium motocross machinery in the highly competitive 2-stroke segment. Enjoying the same, innovative throttle body fuel injection for 2023, the all-new TX 300 continues to lead the way in off-road 2-stroke development.

The 2023 FC 250, FC 350 and FX 350 are powered by all-new 4-stroke engines that are designed to be faster, lighter, and play a vital role in enhancing overall handling. Utilizing the latest technology and electronic rider aids, these models remain at the forefront of motocross and cross-country machinery development alongside the FC 450 and FX 450, which feature a revised and repositioned engine to improve mass centralization.

All machines in the motocross and cross-country line-up are engineered to outperform the competition. Expertly assembled with high quality components for enhanced performance, reliability, and customization, these models are equipped with WP suspension for unsurpassed comfort and straight-line stability. The new WP XACT 48 mm front forks offer more progressive end-of-stroke damping thanks to an improved hydrostop. In addition, the WP XACT rear shock is designed with a refined main piston for improved comfort and features tool-free adjusters for fast setting changes. Complete with ProTaper handlebars, a Brembo clutch, and Dunlop tires, each model is equipped with a map select switch for selectable engine maps and a personalized riding experience.









2023 Husqvarna FX450 Totalmotorcycle.com Features and Benefits

Engine

The FX 450 engine benefits from advanced engineering techniques to deliver maximum performance. For 2023, the engine is tilted two degrees backwards for significantly improved anti-squat behaviour from the chassis while further aiding the centralisation of mass for improved overall handling. Servicing of the FX 450 engine is made easier compared to previous models thanks to the addition of service markers on the engine cases. Lighter for 2023, the 450 cc 4-stroke engine weighs just 59 lb.

Cylinder head

The redesigned SOHC cylinder head is incredibly compact with the camshaft positioned as close to the centre of gravity as possible for significantly improved handling and agility. A new, more durable fine punched cam chain runs on low-friction chain guides for optimal efficiency and improved reliability with a single oil spray jet guaranteeing effective cooling. The lightweight valves are actuated via a rocker arm and feature timing specifically designed to deliver precise levels of torque and throttle response.

Cylinder and piston

The lightweight aluminium cylinder is undoubtedly an engineering masterpiece and features a 95 mm bore with a 63.4 mm stroke. Inside, the CP bridged-box-type piston features anodised annular grooves, adding durability and longer service intervals at a weight of just 327 g. For improved performance, the compression ratio has been increased to 13.1:1 to create an incredible peak power while maintaining its crisp responsiveness.

Crankshaft

The crankshaft is specifically positioned to harness the rotating mass in the ideal centre of gravity resulting in a lightweight and agile handling feel. As such, the inertia produced by the crankshaft is carefully calculated to deliver optimal traction and rideability from the powerful 450cc plant. A plain big end bearing comprising of two force-fitted bearing shells ensure maximum reliability and durability, guaranteeing long service intervals of 90 hours.

Crankcases

Designed for optimised mass centralisation, the FX 450 crankcases arrange the shafts and engine internals in the perfect position to achieve the best possible handling. Manufactured using a high-pressure die-cast production process, the result is a thin, exceptionally strong wall thickness at the lowest possible weight.

DDS clutch

The FX 450 features a (DDS) Dampened Diaphragm Steel clutch, which includes a single-diaphragm steel pressure plate instead of traditional coil springs. It integrates a damping system for better traction and durability. The clutch basket is a single-piece CNC-machined steel component, which has been revised to accomodate the new gearbox in 2023, and continues to allow the use of thin steel liners that contribute to the compact design of the engine.

Gearbox

Produced by PANKL RACING SYSTEMS, the new 5-speed gearbox is designed to be extremely light and durable with a revised transmission ratio of 29:72 offering smooth and precise shifting. Integrated on the shift drum, a new quickshift sensor can be activated on the map select switch to further enhance clutchless upshifting.





Frame

The proven chromium molybdenum steel frame is refined for 2023 to reposition rotational masses inside the engine which together with a new shock mounting position, significantly improves anti-squat behaviour of the chassis. With optimised wall thickness in high-stress areas improving reliability, the frame continues to offer advanced geometries and flex characteristics aimed at providing unparalleled rider feedback, energy absorption, and exceptional straight-line stability. The frame is finished off in a premium metallic blue powder coating with redesigned standard frame protectors offering superior protection, durability, and grip in any condition. Additionally, the inclusion of forged brackets on the lower frame rails allows for easy installation of the standard skid plate.

Polyamide-reinforced aluminium subframe

Made from 60% polyamide and 40% aluminium, the new two-piece subframe for 2023 ensures exceptional strength and durability at an overall weight of just 3.9 lb. The lower subframe spars and frame mounts are manufactured from cast aluminium for significantly improved reliability. The upper section of the subframe is made from injection-moulded polyamide to enable specific flex characteristics and ensure a lightweight construction.

Triple clamps

Matching the new frame design and suspension set-up, the CNC-machined triple clamps provide precisely calculated geometry for increased stability. Customised handlebar flex can be achieved by the new handlebar clamp which offers two mounting options – rubber-damped for less vibration or fixed for enhanced front-end feedback. The upper triple clamp is stiffer to ensure a smoother fork action and plays a vital role in the perfect alignment of the front wheel for superior handling.

WP XACT front suspension

The 48 mm split air WP XACT forks now offer improved bottoming resistance thanks to a new hydrostop, which applies a progressive damping force in the last 40 mm of travel for even greater comfort. The WP forks are designed with a capsulated, adjustable air spring and pressurized oil chamber for smooth action and consistent damping. Oil and air bypasses reduce pressure peaks and in combination with a midvalve damping system, the forks provide precise feedback to the rider. The settings are easily adjusted via the single air pressure pre-load valve, as well as through easy access click adjusters for compression and rebound. For improved durability, new fork protection rings prevent dirt intrusion. Additionally, the air pump needed to adjust the fork’s air pressure is provided as standard.

WP XACT rear suspension

An all-new design results in a 15 mm shorter rear shock, which is 100 g lighter compared to the previous generation while the rear wheel travel is set at 293 mm. Inside the shock is a Computational Fluid Dynamics (CFD) optimised main piston for improved initial comfort which provides strong hold-up in all conditions. Different sized holes in the shims allow them to open more easily which reduces the overall stress of the oil flow. Complete with low friction SKF seals and a revised linkage system, consistent damping, comfort, and traction are guaranteed with rebound and both high and low speed compression now adjustable by hand.

Swingarm

The new hollow die-cast aluminium swingarm is manufactured from a single piece of aluminium using an improved die-cast production process for optimal stiffness and a 190 g weight reduction over previous versions. In order to optimise and match the flex characteristics from the new frame, a new 22 mm rear axle is fitted. Additionally, the chain guard and chain slider have been completely redesigned for improved durability and are less prone to catching on external objects.



Bodywork

Clean, Swedish-inspired design and ergonomics are tailored to deliver exceptional comfort and control, enabling riders to perform at their best for extended periods of time. Adapted after countless hours of testing, the contact points have been repositioned for 2023 and together with a flatter seat profile, riders can move freely on the motorcycle for total control at all times.

Tool-less airbox

Easy access to the TWIN AIR filter is possible without tools, for quicker cleaning and easier maintenance. Precision inlet ducts maximise airflow and offer increased levels of filter protection.

Hydraulic clutch

The high-performance Brembo hydraulic clutch system guarantees even wear, near maintenance-free operation and perfect modulation in every condition. Meaning that play is constantly compensated so that the pressure point, and function of the clutch remain identical in cold or hot conditions, as well as over time. Countless hours of race focused testing have proven the high-quality, Italian-made Brembo hydraulic systems exceptional reliability.

Hydraulic brakes

The highest level of quality is guaranteed with class-leading Brembo callipers made from single pieces of aluminium for strength at the lowest possible weight. Together with a 260 mm front and a 220 mm rear disc removing dirt efficiently, superior stopping power and braking confidence is guaranteed in all conditions.

ProTaper handlebar

Developed between Husqvarna Motorcycles and leading handlebar manufacturer, ProTaper, the exclusive bend offers superior comfort, class-leading strength, and fatigue resistance at the lowest possible weight. Fitted to the handlebar as standard are our open handguards for added protection in the demanding off-road environments.

ODI grips

ODI lock-on grips feature an innovative integrated throttle mechanism and a glue-free installation. The throttle assembly offers easy free-play adjustment with the option to fit alternative cams for a personalised throttle action.

Footrests

All-new, CFD-designed footrests offer a 26.8% larger contact area to ensure better control of the machine while being less susceptible to hooking on deep ruts, take-offs when scrubbing, or trackside barriers. This was achieved by a new, narrower mounting design in the frame layout, which also helps reduce overall weight.



Wheels and tyres

CNC-machined hubs and high-strength alloy rims by D.I.D are finished in striking black. They feature laser engraved logos and are fitted with a DUNLOP GEOMAX MX33 tyre on the front and DUNLOP GEOMAX AT81 tyre on the rear which ensure progressive cornering and superior traction on a variety of terrain.

Exhaust system

Tailored specifically to the FX 450 engine using an innovative 3D design process, the header pipe ensures maximum power across the rev range. The muffler features an aluminium mounting bracket for strength at the lowest possible weight, with an advanced internal construction ensuring excellent noise damping without sacrificing performance.

Cooling system

Manufactured from high-strength aluminium, the radiators are designed using Computational Fluid Dynamics (CFD) to channel air in the most effective way. A large centre tube channels coolant through the frame to reduce pressure at this point in the system for a more consistent flow while a new internal thermostat further enhances reliability.

Fuel tank

A new 2.24 gallon fuel tank integrates neatly into the revised bodywork. Due to the new fuel pump design and position, the tank is emptied further for increased running times. For improved safety, the external fuel line is specifically routed to make it less exposed and susceptible to damage.



Map select switch

A redesigned and intuitive handlebar-mounted map select switch allows riders to activate launch and traction control, and allows riders to toggle between two engine maps. The easy-to-operate map select switch allows racers to quickly alter and set up the engine characteristics on a race by race basis dependent on track conditions and rider preference.

Quickshift

The new quickshift function can be activated or deactivated via the map select switch. The function works only when upshifting, interrupting the ignition for a fraction of a second. This allows upshifting while the throttle is fully open without the use of the clutch. A sensor on the shift drum registers the force from the shift lever, sends the signal to the ECU and the ignition timing is interrupted. To prevent unintended shifts and false neutrals, the function is only active from second gear upwards.

Mapping

For personalised power delivery, the FX 450 has two built-in engine maps as standard. Map 1 offers linear, predictable power, while Map 2 is more aggressive for a sharper throttle response and more explosive power output.

E-Start

As with all 4-strokes in the Husqvarna range, the FX 450 starts with the ease of pressing a button thanks to electric start. A lightweight Li-Ion 2.0 Ah battery is fitted, giving the convenience of electric starting while keeping overall weight to a minimum.

Engine management system

The KEIHIN EMS is designed to be small, lightweight and fast at processing data. It integrates traction control for perfect starts, selectable engine maps via the switch on the handlebar, as well as launch control.

Hour meter

A new hour meter comes with an integrated fuel level indicator, which is visible on the FI status LED, indicating to the rider when the fuel level is becoming low.

Start/stop switch

The new combined start/stop switch is located on the right side of the handlebar for easy, thumb-operated use. Not only simplifying the starting and stopping of the engine, the removal of a designated stop only button from the handlebar reduces the risk of potential damage or activation in the event of a fall.

Traction Control

Traction control on the FX 450 is engaged by a button marked ‘TC’ on the Map Select Switch and functions by analysing throttle input from the rider and the rate at which engine RPM increases. If the RPM increases too quickly, the engine management system (EMS) registers a loss of grip and reduces the amount of power to the rear wheel to ensure maximum traction. This is a distinct advantage in wet or muddy conditions.













2023 Husqvarna FX450 – Totalmotorcycle.com Specifications/Technical Details
US MSRP Price: $ 11649 USD
Canada MSRP Price: $12999 CDN
Europe/UK MSRP Price: £ NA GBP (On The Road inc 20% Vat)

Engine
• Transmission 5-speed
• Starter Electric starter
• Stroke 63.4mm
• Bore 95mm
• Clutch Wet, DDS multi-disc clutch, Brembo hydraulics
• Displacement 449.9cm³
• EMS Keihin EMS
• Design 1-cylinder, 4-stroke engine



Chassis
• Weight (without fuel) 103.5kg
• Tank capacity (approx.) 8.5l
• Front brake disc diameter 260mm
• Rear brake disc diameter 220mm
• Front brake Disc brake
• Rear brake Disc brake
• Chain X-Ring 5/8 x 1/4″
• Frame design Central double-cradle-type 25CrMo4 steel
• Front suspension WP XACT-USD, Ø 48 mm
• Ground clearance 343mm
• Rear suspension WP XACT Monoshock with linkage
• Seat height 948mm
• Steering head angle 63.9°
• Suspension travel (front) 305mm
• Suspension travel (rear) 293mm



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
