2023 Honda CB650R: IN A CLASS OF ITS OWN.
Introducing the 2023 Honda CB650R…
READY TO REV
Want to know the difference between our CBR650R and the CB650R (other than that one little letter)? First you’ll notice the CB650R showcases its engine front and center, uncovered by any bodywork. Next, check out the seating position, especially the taller handlebar. That really opens up the cockpit, letting you sit up a little straighter, especially welcome if you’re riding around in town or at a more relaxed pace. They may seem like small things, but they all add up to a bike that is a real decathlon champion, a machine with an incredibly wide range where it shines. Great suspension, a responsive chassis, anti-lock brakes, six-speed transmission and comfortable rider accommodations: While there’s no such thing as a one-size-fits-all motorcycle, the 2023 CB650R comes awfully close.
FROM BOREDOM TO THRILL AT FIRST SIGHT.
2023 Honda CB650R Totalmotorcycle.com Key Features
STYLING
Tightly wrapped and aggressive, the CB650R’s style features the signature compact “trapezoid” proportion of short, stubby tail and short-overhang headlight. The long fuel tank is a key motif of the family design; its smooth lines accentuate the solidity of real metal surfaces and crown the engineering of the four-cylinder powerplant. It also houses the ignition.
The handlebar is set forward for good ergonomics, and the LCD dash has good visibility. The round headlight is based on that of the CB1000R. It’s LED, as is the rest of the lighting. Sharp LCD instruments also use the CB1000R as a baseline and include Shift Up, Gear Position and a Peak Hold indicator, which brings attention to the peak revs and offers a dynamic experience for the rider.
A 21.9 inch tapered handlebar is shaped and positioned to offer a sporty yet comfortable riding position, as is the foot-peg position. Seat height is 31.9 inches.
CHASSIS / SUSPENSION
The CB650R’s steel-diamond frame uses pressed swingarm pivot plates for weight savings twin elliptical spars with a rigidity balance specifically tuned (stiffer around the headstock and more flexible in the spar sections) to deliver balanced handling characteristics with high levels of rider feedback. Curb weight (measured with all required fluids) is 456 pounds. Much is owed to weight-saving measures in the frame, fuel tank and super-sport-style footpegs. Handling is further aided by an ideal centralization of mass.
Front suspension comprises an inverted 41mm Showa Separate Function Big Piston fork—high-quality suspension that improves the bike’s handling. The fork is held by a forged-aluminum bottom triple clamp. Adjustable for seven-stage spring preload, the single-tube shock operates directly on the curvaceous, gravity die-cast aluminum swingarm.
Four-piston radial-mount front brake calipers work on 310mm floating rotors and are paired with a single-piston rear caliper and 240mm rotor. Two-channel ABS is standard. The cast aluminum wheels are designed with five Y-shaped spokes, reducing weight by front and rear, which also improves handling by reducing inertia and unsprung mass.
ENGINE / DRIVETRAIN
Honda’s development engineers wanted to create the purest, most enjoyable midsized four-cylinder performance possible for the CB650R rider, so the 649cc, DOHC 16-valve engine has been tuned to deliver good power above 10,000 rpm. Peak power arrives at 12,000 rpm, with peak torque delivered at 8,500. The net result is a motor that spins well at high rpm, with a smooth, linear torque delivery that builds strongly as revs rise, and sounds great in the process.
Direct cam actuation makes for a compact cylinder head; compression ratio is 11.6:1. The valve train is reinforced and iridium spark plugs employed.
Asymmetric piston skirts minimize bore contact, reducing friction. Ferrous spines on the outer surface of the cylinder sleeves reduce oil consumption (and friction) with improved heat transfer, and a silent SV cam chain reduces frictional losses by using a Vanadium coating on its pins. Internal water channeling from the cylinder head to the cylinders does away with most of the exterior hoses.
Twin air ducts on either side of the fuel tank feed a large volume of air, raising atmospheric pressure in the airbox. They also produce a throaty intake roar. The exhaust features a large, 1.5 inch-bore tail pipe inside the muffler to flow more gas and, with its exit pipe angled upward, to emit an emotional howl.
The engine uses a compact internal architecture, stacked six-speed gearbox and starter layout with the cylinders canted forward 30°. An assist/slipper clutch eases upshifts while managing rear-wheel lock up under rapid downshifts, while Honda Selectable Torque Control (HSTC) manages rear-wheel traction; it can be turned off should the rider choose.
Transferable one-year, unlimited-mileage limited warranty; extended coverage available with a Honda Protection Plan.
Meets current EPA standards.
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment.
ALUMINIUM WHEELS
The CB650R is equipped with premium 5-spoke Y-shaped aluminium wheels. The innovative design optimises rigidity while cutting down on thickness, giving you maximum strength with minimum weight.
NEW SHOWA SFF-BP USD FORKS
41mm Showa Separate Fork Function Big Piston (SFF-BP) USD forks are an upgrade for the CB650R, and offer supple response with excellent feel for front tyre grip. They match, perfectly the frame’s tuned rigidity balance and quick-steering geometry.
FOUR-CYLINDER ENGINE
The inline four-cylinder, DOHC 16-valve, EURO5-specification engine produces 70kW with strong mid-range torque of 64Nm. It has a 12,000rpm redline and features Honda Selectable Torque Control (HSTC) to maintain rear wheel traction. The ignition switch is housed in the front of the fuel tank cover, to create a minimalist frontal area.
ENHANCED COCKPIT CONTROL
The CB650R features rich digital LCD instruments with new, easy-to-read design; included in the display are Gear Position and Shift Up indicators. The tapered handlebars are now set at a wider, and offer easy leverage for fast steering reaction. You are the king of the urban jungle. Show the world what you’re capable of.
FULL LED LIGHTING
The lighting system of the CB650R is optimally engineered. All lighting is premium LED. The circular headlight, equipped with a sharp black bezel, throws out an intense, blue-tinted beam. The taillight is minimal, and tucks away above the steel number plate mount.
RADIAL-MOUNT CALIPERS
The urban jungle can be unpredictable. That’s why you need a motorcycle that will give you smooth, complete control in any weather. Dual, radial-mount four-piston calipers grip 310mm floating discs, complemented by a single-piston rear caliper and 240mm disc. Dual channel ABS maintains smooth control in wet or dry conditions. Conquer the road, rain or shine.
ALUMINIUM WHEELS
The CB650R is equipped with premium 5-spoke Y-shaped aluminium wheels. The innovative design optimises rigidity while cutting down on thickness, giving you maximum strength with minimum weight.
NEW SHOWA SFF-BP USD FORKS
41mm Showa Separate Fork Function Big Piston (SFF-BP) USD forks are an upgrade for the CB650R, and offer supple response with excellent feel for front tyre grip. They match, perfectly the frame’s tuned rigidity balance and quick-steering geometry.
FOUR-CYLINDER ENGINE
The inline four-cylinder, DOHC 16-valve, EURO5-specification engine produces 70kW with strong mid-range torque of 64Nm. It has a 12,000rpm redline and features Honda Selectable Torque Control (HSTC) to maintain rear wheel traction. The ignition switch is housed in the front of the fuel tank cover, to create a minimalist frontal area.
ENHANCED COCKPIT CONTROL
The CB650R features rich digital LCD instruments with new, easy-to-read design; included in the display are Gear Position and Shift Up indicators. The tapered handlebars are now set at a wider, and offer easy leverage for fast steering reaction. You are the king of the urban jungle. Show the world what you’re capable of.
FULL LED LIGHTING
The lighting system of the CB650R is optimally engineered. All lighting is premium LED. The circular headlight, equipped with a sharp black bezel, throws out an intense, blue-tinted beam. The taillight is minimal, and tucks away above the steel number plate mount.
RADIAL-MOUNT CALIPERS
The urban jungle can be unpredictable. That’s why you need a motorcycle that will give you smooth, complete control in any weather. Dual, radial-mount four-piston calipers grip 310mm floating discs, complemented by a single-piston rear caliper and 240mm disc. Dual channel ABS maintains smooth control in wet or dry conditions. Conquer the road, rain or shine.
Every day is a journey. Start yours today with the CB650R. Distinctive performance of raw sports street fighters and stripped-down Neo Sports Café styling. The CB650R – with style, suspension and equipment updates – is ready to take you on an unforgettable, urban adventure.
LESS IS MORE
Minimum fuss, maximum motorcycle.
The CB650R features a sleek, streamlined design to match your sophisticated urban style. The bike’s ultra-compact, powerful stance channels the retro-minimalism of the CB1000R Neo Sports Café. It blends curved lines with taut angles and, now, is even more dynamic with newly-chiselled side panels and sleek rear number plate mount. With the CB650R, less gives you more.
ADDICTIVE ENGINEERING
Built to be used. And enjoyed.
The inline four-cylinder DOHC 16-valve engine is built to be used. Close, short gearing and a smooth rush of power delivers exhilarating acceleration – and then there’s the evocative howl as rpm climbs high. It’s addictive. An assist/slipper clutch eases upshifts and manages hard down changes, while Honda Selectable Torque Control (HSTC) maintains rear wheel traction. It’s an engineering masterpiece. Have fun with it.
FULLY EQUIPPED
Everything you need. Nothing to get in your way.
A premium motorcycle deserves premium equipment. Full LED lighting adds a sophisticated, contemporary edge, and the distinctive circular headlight throws out a penetrating blue-tinted beam. There also now a USB socket under the seat, for charging your device and the instrument display – with improved clarity – is a crisp LCD dash, and includes Gear Position and Shift Up indicators.
2023 Honda CB650R Totalmotorcycle.com Features and Benefits
PERFORMANCE
649cc DOHC ENGINE
Engines like this are what Honda does best. The four-cylinder design makes it smoother and faster revving than most twins, and offers ample low- to midrange torque, plus plenty of power through the entire rev range.
4.1-GALLON FUEL TANK
A bike as versatile as the CB650R needs plenty of range, and the 4.1-gallon fuel tank provides just that.
FOUR-INTO-ONE EXHAUST
Power, style and an unmistakable growl—you get all three with the four-into-one exhaust system on the CB650R.
Honda SELECTABLE TORQUE CONTROL
With Honda Selectable Torque Control System (HSTC) the CB650R offers you peace of mind during aggressive riding conditions. The system adjusts engine power to optimize torque at the rear wheel, reducing rear-wheel slip. And here’s the best part: you can turn it on or turn it off with a handlebar-mounted switch.
EXHAUST SYSTEM
An exhaust system needs to accomplish four things: To quiet the engine without robbing power, to help tune engine output, to sound great, and they’re a huge style element on any bike. The CB650R’s exhaust knocks it out of the park on all counts, and sounds like only an inline four can.
REFINED INTAKE SYSTEM
The CB650R features a twin-duct intake design, engineered to ram cool, dense air into the airbox, increasing horsepower.
SIX-SPEED TRANSMISSION
Smooth, nearly seamless shifts and gear ratios matched to the way you want to ride: those are two of the characteristics that make this Honda so much fun to ride.
SPECIAL ENGINE TUNING
Changes to valve timing and piston shapes (compared to the previous generation CB650R) have improved engine response, especially from the idle to 8000 rpm, a big advantage in urban environments.
STYLE
CAFÉ STYLING
This bike looks unique, because it is. Its modern Café design combines elements from pure sportbikes and sporting nakeds. Sometimes less is more, and the CB650R makes a bold styling statement wherever you ride it.
DIGITAL INSTRUMENTS
The CB650R’s LCD screen features a digital speedometer and tachometer, plus a clock, odometer, trip meter, real-time and average fuel consumption meters, and illuminated engine diagnostic indicators.
LED HEADLIGHT
The CB650R uses the same LED headlight as our CB1000R. The LED headlight is both brighter and smaller than a conventional design, and the black bezel contributes in a big way to the CB650R’s sense of style.
TRAPEZOIDAL BODY LAYOUT
It sounds like a mouthful, but it just means that the CB650R has some awesome lines, and that it just flat out looks right.
HANDLING
SHOWA® SFF-BP FRONT SUSPENSION
Great handling and precise steering demand a premium front suspension. That’s why the CB650R features a Showa Separate Function Front Fork Big Piston unit (SFF-BP). It offers both reduced weight, superior rigidity, and excellent overall performance.
Y-SPOKE ALUMINUM WHEELS
The aluminum wheels feature “Y”-shaped spokes that help reduce unsprung weight for better handling.
COMFORT
HANDLEBAR
A bike’s handlebar makes a huge difference in how you relate to your machine. We fine-tuned the handlebar angle, and everyone agrees it’s one of our best, making tight, slow-speed turns easier.
FRAME
The twin-spar frame incorporates pivot plates, engine hangers, seat rails, and other components that all reduce weight. It’s light, strong, and provides the basis for the CB650R’s stellar handling.
NEUTRAL/SPORTING RIDING POSITION
One of the most rider-friendly aspects of the whole Café design is how you sit on the CB650R. You’re ready for aggressive riding, but you’re still comfortable. You can see what’s going on around you. And your riding sessions can last for hours at a time with little fatigue.
RADIAL-MOUNT FRONT BRAKES
Featuring large-diameter 310mm discs, the CB650R also comes with radial-mounted four-piston calipers. The result is premium sportbike stopping power that’s linear and easy to modulate.
REAR-DISC BRAKE
A 240mm hydraulic disc at the rear complements the twin front discs for plenty of stopping power.
SLIPPER CLUTCH
The assist slipper clutch lightens clutch operation by approximately 12 percent compared to previous designs, and that reduces rear-wheel hop during rapid downshifts.
2023 Honda CB650R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $9,399 USD
Canada MSRP Price: $11,229 CDN
Europe/UK MSRP Price: £ See Dealer for pricing in GBP (On The Road inc 20% Vat)
ENGINE
Engine Type 649cc liquid cooled in-line four cylinder
Bore And Stroke 67.0mm x 46.0mm
Compression Ratio 11.6:1
Valve Train DOHC; four valves per cylinder
Induction PGM-FI with 32mm throttle bodies
DRIVE TRAIN
Transmission Six-speed
Final Drive #525 Chain; 15T/42T
CHASSIS SUSPENSION BRAKES
Front Suspension 41mm fork; 4.7-inch travel
Rear Suspension Showa Single Shock; 5.1-inch travel
Front Brake Dual 310mm discs with radial-mount four-piston calipers; ABS
Rear Brake Single 240mm disc; ABS
Front Tire 120/70-17
Rear Tire 180/55-17
DIMENSIONS
Rake (Caster Angle) 25.0°
Trail 4.0 inches
Wheelbase 57.0 inches
Seat Height 31.9 inches
Curb Weight 445 pounds (Includes all standard equipment, required fluids and full tank of fuel.)
Fuel Capacity 4.1 gallons, including 0.8-gallon reserve
Miles Per Gallon TBD
OTHER
Model ID CB650RA
Emissions Meets current EPA standards. California version meets current CARB standards and
may differ slightly due to emissions equipment.
Available Colors Matte Black Metallic
FACTORY WARRANTY INFORMATION
One Year Included Transferable, unlimited-mileage limited warranty
Optional Extended Extended coverage available with a HondaCare® Protection Plan
2023 Honda CB650R – Totalmotorcycle.com Canada Specifications/Technical Details
Engine & Drivetrain
Engine Type Liquid-cooled inline four cylinder
Displacement 649 cc
Bore & Stroke 67 mm x 46 mm
Compression Ratio 11.6:1
Valve Train DOHC, four valves per cylinder
Fuel Delivery PGM-FI electronic fuel injection with 32 mm throttle bodies
Transmission Six-speed
Final Drive #525 chain (15T/42T)
Chassis & Suspension
Front Suspension 41 mm Showa SFF-BP (Separate Function- Big Piston front Fork) inverted fork; 108 mm (4.3 in) travel
Rear Suspension Showa monoshock damper with 7-stage adjustable preload; 128 mm (5 in) travel
Additional Information
Tires Front: 120/70-17
Rear: 180/55-17
Brakes Front: Dual 320 mm discs
Rear: 240 mm disc
ABS System 2-channel
Seat Height 810 mm (31.9 in.)
Wheelbase 1,450 mm (57.1 in.)
Curb Weight 201kg (445 lb.)
Fuel Capacity 15.4 L
Colour Mat Gunpowder Black Metallic (Black Edition)
Warranty 12 months, unlimited mileage, freely transferable warranty; extended coverage available with Honda Plus
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
