2023 Harley-Davidson X350 Guide

2023 Harley-Davidson X350
ReviewKey FeaturesFeatures & BenefitsSpecifications

2023 Harley-Davidson X350 2023 Harley-Davidson X350 2023 Harley-Davidson X350 2023 Harley-Davidson X350 2023 Harley-Davidson X350 2023 Harley-Davidson X350 2023 Harley-Davidson X350

2023 Harley-Davidson X350: NIGHT LIFE. URBAN LIFE. AN EXCITING LIFE.

Introducing the 2023 Harley-Davidson X350…

Lightweight and agile, it can open any door in the city. Classic design lines suitable for urban life. Confidently control the urban combustion engine journey.







2023 Harley-Davidson X350 Totalmotorcycle.com Key Features

  • More domineering riding posture
  • Center foot controls
  • Passenger seat
  • Safe Riding Enhancements
  • Liquid-cooled, strong and reliable 353cc engine
  • Road track racing styling and design
  • Two-person ride-on with passenger rear seat and footrests







2023 Harley-Davidson X350 Totalmotorcycle.com Features and Benefits

LIGHT UP THE NIGHT
Full LED lighting balances styling and performance

HOT ENGINE “MULTIPLY” DOUBLE
Equipped with a passenger rear seat and pedals, two people travel passionately

STREET RIDING SHOW
Light and agile, the engine is tuned for strong mid-range torque

AMERICAN FLAT-TRACKER SHAPE
Inspired by the legendary Harley-Davidson XR750’s design

LIQUID-COOLED, RUGGED AND RELIABLE
353cc engine, stable performance output to easily control any riding situation

THE NARROW SHAPE OF THE FRONT OF THE SEAT AND THE REAR OF THE FUEL TANK
It is conducive to gripping the vehicle during braking and turning operations, and satisfies most riders to park confidently with their feet flat.

Adjustable front and rear suspension puts you in control, combining comfort and performance.







2023 Harley-Davidson X350 – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ TBA USD
Canada MSRP Price: $ TBA CDN
Europe/UK MSRP Price: £ TBA GBP (On The Road inc 20% Vat)

TBA





2023 Harley-Davidson X350 – Totalmotorcycle.com Canada Specifications/Technical Details

TBA





2023 Harley-Davidson X350 – Totalmotorcycle.com Europe Specifications/Technical Details

ASIA Specifications Below

SIZE

LENGTH

2,110 mm

SEAT HEIGHT, LESS THAN FULLY LOADED

817 mm

GROUND CLEARANCE

185 mm

FORWARD TILT

24.8

TRAILING DISTANCE

140 mm

WHEELBASE

1,410 mm

TIRES, FRONT WHEEL SPECIFICATIONS

120/70-ZR17/58W

TIRES, REAR SPECIFICATIONS

160/60-ZR17/69W

TIRE TYPE

Maxxis Supermaxx ST

FUEL CAPACITY

13.5 l

OIL CAPACITY (WITH FILTER)

3.2 liters

FACTORY WEIGHT

180 kg

DRIVING WEIGHT

195 kg

ENGINE

ENGINE 2

Liquid-cooled, in-line twin, 353cc

BORE

70.5 mm

STROKE

45.2 mm

DISPLACEMENT

353 cc

COMPRESSION RATIO

11.9:1

FUEL SYSTEM

Electronic Air Intake Fuel Injection (ESPFI)

EXHAUST

2 in 1 short out

PERFORMANCE

ENGINE TORQUE TEST METHOD

GB/T20076-2006, GB/T5363-2008

ENGINE TORQUE 3

31 Nm

ENGINE TORQUE (REV/MIN)

7000

HORSEPOWER

27kW

BODY ROLL, RIGHT LEAN (ANGLE)

52

BODY LEAN, LEFT LEAN (ANGLE)

51

FUEL ECONOMY TEST METHOD

WMTC

FUEL ECONOMY

4.95 l/100 km

CO2 EMISSIONS TEST METHOD

WMTC

CARBON DIOXIDE EMISSIONS

115 g/km CO2

TRANSMISSION SYSTEM

MAIN DRIVE

Chain, 82/31

GEAR RATIO (TOTAL) 1ST GEAR

3.167

GEAR RATIO (OVERALL) 2 GEARS

2.056

GEAR RATIO (TOTAL) 3RD GEAR

1.556

GEAR RATIO (TOTAL) 4TH GEAR

1.333

GEAR RATIO (TOTAL) 5TH GEAR

1.19

GEAR RATIO (TOTAL) 6 GEARS

1

FRAME

FRONT FORK

41mm inverted rebound adjustable

REAR SHOCK ABSORBER

Oil-air separation, rebound damping adjustable, preload adjustable shock absorber

FRONT HUB 4

cast aluminum

REAR HUB 4

cast aluminum

BRAKES, DISC TYPE

Brake disc type front floating, rear fixed

BRAKE, CALIPER TYPE

Front brake 4 fixed pistons Rear brake single sliding piston

ELECTRICAL SYSTEM

LIGHTS (REQUIRED BY COUNTRY LAW), PILOT LIGHTS

Front Lights: All LED, Low Beam, High Beam and Iconic Position Lights; Tail Lights/Parking Lights: All LED Lights; Front Signal Lights: All LED Lights; Rear Turn Signal Lights: Full LED

METER

Combined electronic instrument Stepper motor indicates vehicle speed, digital indicates speed, hour, total travel, two-way (A+B), km/mile indication





Notes:

  1. 91 octane (95) or better fuel is recommended (R+M)/2.
  2. Values ​​shown are nominal values. Product performance may vary in different countries and regions.
  3. Standard and optional rims may vary in different countries and regions.
    *Ride range estimates provided in accordance with WMTC 134/2014 Annex VII Appendix 3.3, based on expected performance of a fully charged battery when driven under specified conditions. Actual mileage will vary based on riding habits, surrounding weather and equipment condition.
  4. The displayed mileage is from maximum power and minimum regeneration.





Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
