2022 Honda Montesa Cota 4RT260R Guide

2022 Honda Montesa Cota 4RT260R

2022 Honda Montesa Cota 4RT260R 2022 Honda Montesa Cota 4RT260R 2022 Honda Montesa Cota 4RT260R 2022 Honda Montesa Cota 4RT260R

2022 Honda Montesa Cota 4RT260R: COMPETITION READY.

Introducing the 2022 Honda Montesa Cota 4RT260R…

The latest evolution of Montesa’s versatile 259 cc platform, this model acquires the “R” suffix for 2022, indicating it to be more competition-ready than its predecessor. Upgrades include the switch to Showa suspension components, as well as the larger aluminum muffler from the 301 platform, which delivers increased horsepower across the rev range. The 4RT260R also gets new graphics and a striking black color.

With considerable input from perennial FIM Trial World Champion Toni Bou, Honda subsidiary Montesa continues to develop the most advanced trials machines on the planet. Designed, developed and produced in the company’s Spanish factory – located in the trials hotbed of Barcelona, and with a heritage that extends back even longer than that of Honda – the 4RT260R and 4RT301RR Race Replica are elite machines capable of tackling the most impossible sections imaginable.





2022 Honda Montesa Cota 4RT260R Totalmotorcycle.com Key Features









2022 Honda Montesa Cota 4RT260R Totalmotorcycle.com Features and Benefits

ENGINE / DRIVETRAIN

  • The 4RT260R has a displacement of 259 cc, delivered via a 78.0 mm bore and a 54.2 mm stroke.
  • With bore and stroke figures of 81.5 mm and 57.2 mm, the 4RT301RR Race Replica has an engine displacement of 298 cc, the maximum allowed in the FIM Trial2 World Championship.
  • Power is biased to the low end and midrange for the smooth, tractable delivery that is vital for maintaining traction in technical conditions, even with the sudden bursts of acceleration common in trials riding.
  • The three-ring piston and specially designed crankshaft reduce vibration.
  • Programmed electronic fuel injection for smooth running in varying conditions.
  • Large, lightweight aluminum muffler, for maximum torque across the rev range.
  • The light-but-tough carbon-fiber guard protects the clutch, on the engine’s right side.
  • The decompression system features a large, 2.3 mm crankcase breather tube for reduced engine braking, helping to maintain traction during deceleration.

CHASSIS / SUSPENSION

  • Lightweight 39 mm Showa fork has adjustable compression and rebound damping, as well as adjustable preload. Travel is 6.2 inches.
  • The Pro-Link® rear-suspension system with single Showa shock absorbs trials sections’ gnarliest obstacles. Travel is 6.7 inches.
  • Lightweight aluminum frame and swingarm for nimble handling.
  • Aluminum wheel hubs minimize unsprung weight for easy steering and predictable handling.
  • Petal-style Galfer rotors front and rear, for optimum braking power and modulation. A four-piston front caliper offers strong, predictable braking, and it’s protected by a plastic guard.
  • A large aluminum skid plate with a rubber cushion protects the engine from the impacts against rocks so common in trials.
  • An aluminum side stand lets the rider easily park the bike when waiting for his or her turn to enter a section.
  • Aluminum fuel tank.
  • Rear fender flares out at the end to better protect the rider from mud and water in transfer sections.
  • Minimalist LED headlight adds illumination in dark conditions (not road legal).











2022 Honda Montesa Cota 4RT260R – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $ See Dealer USD
Canada MSRP Price: $ See Dealer CDN
Europe/UK MSRP Price: £ See Dealer GBP (On The Road inc 20% Vat)
Model

Montesa Cota 4RT260R

Montesa Cota 4RT301RR Race Replica

ENGINE

Type

258.9 cc liquid-cooled, single-cylinder four-stroke

298.0 cc liquid-cooled, single-cylinder four-

Valve Train

SOHC; four valves

Bore x Stroke

78.0 mm x 54.2 mm

81.5 mm x 57.2 mm

Compression Ratio

10.5:1

10.4:1

Induction

Electronic Fuel Injection (PGM-FI)

Ignition

Electronically controlled digital transistorized

Starter

Kick

Transmission

5-speed manual, constant mesh

Clutch

Multiplate wet w/ coil springs; hydraulically operated

Final Drive

Chain

SUSPENSION

Front

Showa 39 mm telescopic fork; adjustable preload, compression, rebound; 6.2 in. travel

Rear

Pro-Link® system w/ single Showa shock; adjustable preload, rebound; 6.7 in. travel

BRAKES

Front

Single 4-piston hydraulic caliper w/ 185 x 3.0 mm Galfer rotor; sintered metal pads

Rear

Single 2-piston hydraulic caliper w/ 150 x 3.0 mm Galfer rotor; sintered metal pads

TIRES

Front

80/100-21 Dunlop

2.75 – 21 Michelin

Rear

120/100-R18 Dunlop

4.00 – R18 Michelin

MEASUREMENTS

Rake (Caster Angle)

23º

24.5º

Trail

63 mm (2.48 in.)

Length

79.5 in.

Width

33.1 in.

Height

44.7 in.

Ground Clearance

13.2 in.

Seat Height

25.6 in.

Wheelbase

52.0 in.

Fuel Capacity

.5 gal.

Curb Weight*

161.0 lbs.

OTHER

Color

Black

White

Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment Specifications subject to change





2022 Honda Montesa Cota 4RT260R – Totalmotorcycle.com Canada Specifications/Technical Details
Model

Montesa Cota 4RT260R

Montesa Cota 4RT301RR Race Replica

ENGINE

Type

258.9 cc liquid-cooled, single-cylinder four-stroke

298.0 cc liquid-cooled, single-cylinder four-

Valve Train

SOHC; four valves

Bore x Stroke

78.0 mm x 54.2 mm

81.5 mm x 57.2 mm

Compression Ratio

10.5:1

10.4:1

Induction

Electronic Fuel Injection (PGM-FI)

Ignition

Electronically controlled digital transistorized

Starter

Kick

Transmission

5-speed manual, constant mesh

Clutch

Multiplate wet w/ coil springs; hydraulically operated

Final Drive

Chain

SUSPENSION

Front

Showa 39 mm telescopic fork; adjustable preload, compression, rebound; 6.2 in. travel

Rear

Pro-Link® system w/ single Showa shock; adjustable preload, rebound; 6.7 in. travel

BRAKES

Front

Single 4-piston hydraulic caliper w/ 185 x 3.0 mm Galfer rotor; sintered metal pads

Rear

Single 2-piston hydraulic caliper w/ 150 x 3.0 mm Galfer rotor; sintered metal pads

TIRES

Front

80/100-21 Dunlop

2.75 – 21 Michelin

Rear

120/100-R18 Dunlop

4.00 – R18 Michelin

MEASUREMENTS

Rake (Caster Angle)

23º

24.5º

Trail

63 mm (2.48 in.)

Length

79.5 in.

Width

33.1 in.

Height

44.7 in.

Ground Clearance

13.2 in.

Seat Height

25.6 in.

Wheelbase

52.0 in.

Fuel Capacity

.5 gal.

Curb Weight*

161.0 lbs.

OTHER

Color

Black

White

Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment Specifications subject to change







2022 Honda Montesa Cota 4RT260R – Totalmotorcycle.com European Specifications/Technical Details
Model

Montesa Cota 4RT260R

Montesa Cota 4RT301RR Race Replica

ENGINE

Type

258.9 cc liquid-cooled, single-cylinder four-stroke

298.0 cc liquid-cooled, single-cylinder four-

Valve Train

SOHC; four valves

Bore x Stroke

78.0 mm x 54.2 mm

81.5 mm x 57.2 mm

Compression Ratio

10.5:1

10.4:1

Induction

Electronic Fuel Injection (PGM-FI)

Ignition

Electronically controlled digital transistorized

Starter

Kick

Transmission

5-speed manual, constant mesh

Clutch

Multiplate wet w/ coil springs; hydraulically operated

Final Drive

Chain

SUSPENSION

Front

Showa 39 mm telescopic fork; adjustable preload, compression, rebound; 6.2 in. travel

Rear

Pro-Link® system w/ single Showa shock; adjustable preload, rebound; 6.7 in. travel

BRAKES

Front

Single 4-piston hydraulic caliper w/ 185 x 3.0 mm Galfer rotor; sintered metal pads

Rear

Single 2-piston hydraulic caliper w/ 150 x 3.0 mm Galfer rotor; sintered metal pads

TIRES

Front

80/100-21 Dunlop

2.75 – 21 Michelin

Rear

120/100-R18 Dunlop

4.00 – R18 Michelin

MEASUREMENTS

Rake (Caster Angle)

23º

24.5º

Trail

63 mm (2.48 in.)

Length

79.5 in.

Width

33.1 in.

Height

44.7 in.

Ground Clearance

13.2 in.

Seat Height

25.6 in.

Wheelbase

52.0 in.

Fuel Capacity

.5 gal.

Curb Weight*

161.0 lbs.

OTHER

Color

Black

White

Meets current EPA standards
Models sold in California meet current CARB standards and may differ slightly due to emissions equipment Specifications subject to change







Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
