2022 Ducati XDiavel S: CUTTING EDGE DUCATI.
Introducing the new 2022 Ducati XDiavel S…
The XDiavel S embodies the sports side of the Ducati cruise. You can tell it is a Ducati at the first corner: the way it leans, its technical content, its cutting-edge electronic package and high performance guarantee an unforgettable riding experience.
2022 Ducati XDiavel S Totalmotorcycle.com Key Features
DISPLACEMENT
1,262 cc (77.0 cu in)
POWER
152 hp (112 kW) @ 9,500 rpm
TORQUE
12.8 kgm (126 Nm, 92.9 lb ft) @ 5,000 rpm
DRY WEIGHT
223 kg (492 lb)
2022 Ducati XDiavel S Totalmotorcycle.com Features and Benefits
Testastretta DVT 1262
The Testastretta DVT 1262 twin-cylinder engine, beating heart of XDiavel, delivers a maximum power output of 152 hp at 9,500 rpm and a maximum torque of 92.9 lb ft at 5,000 rpm.
Torque always available
Approximately 80% of the maximum torque of the XDiavel is almost immediately available: at 2,100 rpm. This means you can pick up speed without having to shift down a gear, by sightly opening the throttle. Just like you expect from a cruiser. The torque peak – 92.9 lb ft – is reached instead at 5,000 rpm, a pretty low speed for a Ducati twin-cylinder engine. If you want the maximum, when the rev counter pointer reaches 9,500 rpm, the wheel gets 152 hp.
Ducati Power Launch
The spirit of the XDiavel can be fully expressed thanks to the Ducati Power Launch. This system can guarantee fast and safe starts thanks to the Bosch IMU which regulates the gas.
Ride-by-Wire
The Ride-by-Wire system is an electronic interface between the engine and the XDiavel’s fuel grip, which allows the ideal power level to be configured depending on the Riding Mode selected.
Belt transmission
The XDiavel is the first Ducati to use belt final drive. A must in the cruiser world, the system was developed for the XDiavel by Ducati engineers so as to be able to guarantee reliable and safe transmission of the power supplied by the Ducati Testastretta DVT 1262.
Forward footpegs
The XDiavel ergonomic started from a basic concept: a relaxed riding position, like a real cruiser, with a low seat and forward footpegs. The footpegs of the XDiavel can be adjusted as standard in three positions (+/- 22.5 mm compared to the standard position).
Adjustable suspension
The adjustable XDiavel suspensions guarantee high comfort even on long distances and perfect control during fast riding.
Brembo braking system
The XDiavel is equipped, as standard, with the Brembo braking system with Bosch 9.1ME ABS Cornering. ABS Cornering makes use of the IMU (Inertial Measurement Unit) platform by Bosch to optimise the braking power of the front and back wheels, also in critical situations and when cornering.
Tires and wheels
At the front the wheel is 3.5″ x 17”, while at the back it is 8″ x 17”. The large rear tyre uses double compound technology to increase grip during the most extreme cornering, guaranteeing at the same time high kilometric performance and applying Enhanced Patch Technology to maximise the contact area with any lean angle. The tread design and the compounds used guarantee exceptional performance in all conditions, especially in the wet.
Riding Mode
The XDiavel integrates the latest innovations in Ducati technology, such as Riding Modes. The three Riding Modes work by combining different cutting-edge technologies, such as Ride-by-Wire, Ducati Traction Control and ABS Cornering Bosch systems.
Ducati Traction Control
DTC is a very smart system which acts as a “filter” between the rider’s right hand and the rear wheel.
Full LED lighting system with DRL
The XDiavel S features a dominant front headlight with Daytime Running Light. The DRL is a particular light which guarantees perfect visibility of the bike during the day and, at the same time, thanks to its particular form, makes the XDiavel S instantly recognisable also in sunlight.
2022 Ducati XDiavel S – Totalmotorcycle.com USA Specifications/Technical Details
US MSRP Price: $25595 USD
Canada MSRP Price: $28795 CDN
Europe/UK MSRP Price: £21995 GBP (On The Road inc 20% Vat)
Type
Testastretta DVT 1262, V2 – 90°, 4 valves per cylinder, Desmodromic Variable Timing, Dual Spark, liquid cooled
Displacement
1,262 cc (77.0 cu in)
Bore x Stroke
106 mm x 71.5 mm
Compression Ratio
13.0:1
Power
152 hp (112 kW) @ 9,500 rpm
Torque
12.8 kgm (126 Nm, 92.9 lb ft) @ 5,000 rpm
Fuel Injection
Electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Exhaust
Stainless steel muffler, catalytic converter and 2 lambda probes
Gearbox
6 speed
Primary drive
Straight cut gears, ratio 1.84:1
Ratio
1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Final drive
Belt, front sprocket z28, rear sprocket z80
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Frame
Tubular steel trellis frame
Front suspension
Adjustable Ø 50 mm usd fork with DLC treatment
Front Wheel
Light alloy, cast and machined, 3.5″x17″
Front Tyre
Pirelli Diablo Rosso III 120/70 ZR17
Rear suspension
Preload and rebound adjustable monoshock, remote reservoir, single-sided cast/trellis frame swingarm
Rear Wheel
Light alloy, cast and machined, 8.0″ x 17″
Rear Tyre
Pirelli Diablo Rosso III 240/45 ZR17
Wheel Travel (Front/Rear)
120 mm / 110 mm (4.7 in / 4.3 in)
Front Brake
2 x Ø 320 mm semifloating discs, radial mounted Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder, Cornering ABS
Rear Brake
Ø 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS
Instrumentation
3.5″ TFT colour display and dedicated warning light display
Dry Weight
223 kg (492 lb)
Kerb Weight
249 kg (549 lb)
Seat Height
755 mm (29.7 in)
Wheelbase
1,615 mm (63.6 in)
Rake
30°
Trail
130 mm (5.1 in)
Fuel Tank Capacity
18 l (4.8 US gal)
Number of Seats
2
Safety Equipment
Riding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Full-LED lighting system, Daytime Running Light
Standard Equipment
Ducati Power Launch, Cruise control, Hands-free, Backlit handlebar switches, 3.5″ TFT colour display, Ducati Multimedia System
Provided Equipment
Passenger comfort seat, Backrest
Warranty
24 months, unlimited mileage
Maintenance Service Intervals
15,000 km (9,000 mi) / 12 months
Valve Clearance Check (Desmoservice)
30,000 km (18,000 mi)
2022 Ducati XDiavel S – Totalmotorcycle.com Canada Specifications/Technical Details
Type
Testastretta DVT 1262, V2 – 90°, 4 valves per cylinder, Desmodromic Variable Timing, Dual Spark, liquid cooled
Displacement
1,262 cc (77.0 cu in)
Bore x Stroke
106 mm x 71.5 mm
Compression Ratio
13.0:1
Power
152 hp (112 kW) @ 9,500 rpm
Torque
12.8 kgm (126 Nm, 92.9 lb ft) @ 5,000 rpm
Fuel Injection
Electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Exhaust
Stainless steel muffler, catalytic converter and 2 lambda probes
Gearbox
6 speed
Primary drive
Straight cut gears, ratio 1.84:1
Ratio
1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Final drive
Belt, front sprocket z28, rear sprocket z80
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Frame
Tubular steel trellis frame
Front suspension
Adjustable Ø 50 mm usd fork with DLC treatment
Front Wheel
Light alloy, cast and machined, 3.5″x17″
Front Tyre
Pirelli Diablo Rosso III 120/70 ZR17
Rear suspension
Preload and rebound adjustable monoshock, remote reservoir, single-sided cast/trellis frame swingarm
Rear Wheel
Light alloy, cast and machined, 8.0″ x 17″
Rear Tyre
Pirelli Diablo Rosso III 240/45 ZR17
Wheel Travel (Front/Rear)
120 mm / 110 mm (4.7 in / 4.3 in)
Front Brake
2 x Ø 320 mm semifloating discs, radial mounted Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder, Cornering ABS
Rear Brake
Ø 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS
Instrumentation
3.5″ TFT colour display and dedicated warning light display
Dry Weight
223 kg (492 lb)
Kerb Weight
249 kg (549 lb)
Seat Height
755 mm (29.7 in)
Wheelbase
1,615 mm (63.6 in)
Rake
30°
Trail
130 mm (5.1 in)
Fuel Tank Capacity
18 l (4.8 US gal)
Number of Seats
2
Safety Equipment
Riding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Full-LED lighting system, Daytime Running Light
Standard Equipment
Ducati Power Launch, Cruise control, Hands-free, Backlit handlebar switches, 3.5″ TFT colour display, Ducati Multimedia System
Warranty
24 months, unlimited mileage
Maintenance Service Intervals
15,000 km (9,000 mi) / 12 months
Valve Clearance Check (Desmoservice)
30,000 km (18,000 mi)
2022 Ducati XDiavel S – Totalmotorcycle.com European Specifications/Technical Details
Type
Testastretta DVT 1262, V2 – 90°, 4 valves per cylinder, Desmodromic Variable Timing, Dual Spark, liquid cooled
Displacement
1,262 cc (77.0 cu in)
Bore x Stroke
106 mm x 71.5 mm
Compression Ratio
13.0:1
Power
160 hp (118 kW) @ 9,500 rpm
Torque
13.0 kgm (127 Nm, 93.7 lb ft) @ 5,000 rpm
Fuel Injection
Electronic fuel injection system, Øeq 56 mm elliptical throttle bodies with Ride-by-Wire system
Exhaust
Stainless steel muffler, catalytic converter and 2 lambda probes
Gearbox
6 speed
Primary drive
Straight cut gears, ratio 1.84:1
Ratio
1=37/15 2=30/17 3=27/20 4=24/22 5=23/24 6=22/25
Final drive
Belt, front sprocket z28, rear sprocket z80
Clutch
Slipper and self-servo wet multiplate clutch with hydraulic control
Frame
Tubular steel trellis frame
Front suspension
Adjustable Ø 50 mm usd fork with DLC treatment
Front Wheel
Light alloy, cast and machined, 3.5″x17″
Front Tyre
Pirelli Diablo Rosso III 120/70 ZR17
Rear suspension
Preload and rebound adjustable monoshock, remote reservoir, single-sided cast/trellis frame swingarm
Rear Wheel
Light alloy, cast and machined, 8.0″ x 17″
Rear Tyre
Pirelli Diablo Rosso III 240/45 ZR17
Wheel Travel (Front/Rear)
120 mm / 110 mm (4.7 in / 4.3 in)
Front Brake
2 x Ø 320 mm semifloating discs, radial mounted Brembo monobloc 4-piston M50 callipers, PR16/19 radial master cylinder, Cornering ABS
Rear Brake
Ø 265 mm disc, Brembo 2-piston floating calliper, Cornering ABS
Instrumentation
3.5″ TFT colour display and dedicated warning light display
Dry Weight
223 kg (492 lb)
Kerb Weight
249 kg (549 lb)
Seat Height
755 mm (29.7 in)
Wheelbase
1,615 mm (63.6 in)
Rake
30°
Trail
130 mm (5.1 in)
Fuel Tank Capacity
18 l (4.8 US gal)
Number of Seats
2
Safety Equipment
Riding Modes, Power Modes, Cornering ABS, Ducati Traction Control, Full-LED lighting system, Daytime Running Light
Standard Equipment
Ducati Power Launch, Cruise control, Hands-free, Backlit handlebar switches, 3.5″ TFT colour display, Ducati Multimedia System
Warranty
24 months, unlimited mileage
Maintenance Service Intervals
15,000 km (9,000 mi) / 12 months
Valve Clearance Check (Desmoservice)
30,000 km (18,000 mi)
Standard
Euro 5
CO2 Emissions
129 g/km
Consumption
5.5 l/100 km
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
