ADRENALINE MIXED WITH A SHOT OF GARAGE-BUILT CUSTOM STYLE.
2020 Harley-Davidson Roadster:
The adrenaline of the Roadster™ comes from a 1200cc V-Twin, 43mm inverted front forks, dual disc brakes, adjustable rear suspension, speedo with tach, mid-mount controls, and lowered bars. The style? Chopped rear fender, side mount license plate (US only), 19” front and 18” rear wheels, iconic tank and new graphics.
It’s a street-eating machine with tucked in, fast back style and 1200cc of corner-cranking torque.
2020 Harley-Davidson Roadster Totalmotorcycle.com Key Features
The Sportster® motorcycle has been a feature on the motorcycling landscape since it first hit the scene in 1957. This is the machine that’s done it all. Drag racing, flat track racing, land speed records, and every kind of street riding or cross-country trek riders could dream up. Simple, righteous, bare-knuckle style. Legendary engine. Easily affordable. Infinitely customizable. Updated for the modern era. Take it wherever you want to go.
Engine
Air-cooled, Evolution®
Engine Torque
76 ft-lb
Weight, As Shipped
551 lb.
Seat Height, Laden
29.5 in.
2020 Harley-Davidson Roadster Totalmotorcycle.com Features
1200 cc Air-Cooled Evolution® Engine
An iconic V-Twin engine that is renowned for its massive low-end torque and soul-satisfying sound. Lightweight aluminium heads and cylinders improve air-cooling efficiency.
Blacked-Out Styling
There’s plenty of black to bring a dark edge to the garage-built look of the Roadster™ motorcycle. The mirrors, belt guard and headlamp are black. The oval air cleaner has a black insert. There are slotted black exhaust shields and a blacked-out powertrain.
Lowered bars & Speedo with Tach
You get the performance, and the look and feel of slammed handlebars that put you in an aggressive riding position. The gauge includes a speedometer and tach so you can keep track of what’s going on in your power plant.
43mm Front Suspension with Inverted Forks
The 43mm front suspension with inverted forks features cartridge damping and the brawny look of massive new triple clamps. They’ll keep your rubber on the road when the pavement gets rough.
Dual Disc Front Brakes with Floating Rotors
Dual disc front brakes with floating rotors so you can be more confident in your stopping with all that muscle behind you.
Aggressive and Comfortable Two-Up Seat
The optimal combination of comfort and custom style. It’s a low profile, two-up seat with a nice, deep scoop to keep you firmly planted under acceleration, and it puts you just 29.5 inches off the ground for a low center of gravity and confident handling.
Light-Weight Offset Split 5-Spoke Wheels
19-inch front and 18-inch rear wheels that give the bike a custom look, easy-steering and a better power to weight ratio.
2020 Harley-Davidson Roadster – Totalmotorcycle.com American Specifications/Technical Details
US MSRP Price from: $11499 USD
Canada MSRP Price from: $12999 CDN
Europe/UK MSRP Price: £ GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AUS
Pricing
- Vivid Black $11,499
- Color $11,849
- ABS Option $795
- Security System Option $395
- California Emissions $100
- Freight $360
Engine
- Engine1 Air-cooled, Evolution®
- Bore 3.5 in.
- Stroke 3.8 in.
- Displacement 73.4 cu in
- Compression Ratio 10:01
- Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust Shorty-dual exhaust with chrome tapered mufflers with laser cut black heat shields
Dimensions
- Length 86 in.
- Seat Height, Laden7 29.5 in.
- Ground Clearance 5.9 in.
- Rake (steering head) (deg) 28.9
- Trail 5.5 in.
- Wheelbase 59.3 in.
- Tires, Front Specification 120/70R19 M/C
- Tires, Rear Specification 150/70R18 M/C
- Fuel Capacity 3.3 gal.
- Oil Capacity (w/filter) 2.8 qt.
- Weight, As Shipped 551 lb.
- Weight, In Running Order 571 lb.
Performance
- Engine Torque Testing Method J1349
- Engine Torque2 76 ft-lb
- Engine Torque (rpm) 3,750
- Lean Angle, Right (deg.) 30.8
- Lean Angle, Left (deg.) 31.1
- Fuel Economy Testing Method Estimated City/Hwy
- Fuel Economy5 48 mpg
Drivetrain
- Primary Drive Chain, 38/57 ratio
- Gear Ratios (overall) 1st 9.315
- Gear Ratios (overall) 2nd 6.653
- Gear Ratios (overall) 3rd 4.948
- Gear Ratios (overall) 4th 4.102
- Gear Ratios (overall) 5th 3.517
Chassis
- Wheels, Front Type7 Black Offset, Split 5-Spoke Cast Aluminum
- Wheels, Rear Type Black Offset, Split 5-Spoke Cast Aluminum
- Brakes, Caliper Type Dual-piston front, Dual-piston rear
Electric
- Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engie diagnostics, low fuel warning, low battery, security system (If equipped), ABS (if equipped)
- Gauges Dual Gauge – 4 “Digital Speedometer / Analog Tachometer
2020 Harley-Davidson Roadster – Totalmotorcycle.com Canadian Specifications/Technical Details
Pricing
- Vivid Black $ 12,999
- Colour $ 13,399
- ABS Option $ 615
- Security System Option $ 355
Engine
- Engine1 Air-cooled, Evolution®
- Bore 88.9 mm
- Stroke 96.8 mm
- Displacement 1,202 cc
- Compression Ratio 10:1
- Fuel System3 Electronic Sequential Port Fuel Injection (ESPFI)
- Exhaust Shorty-dual exhaust with chrome tapered mufflers with laser cut black heat shields
Dimensions
- Length 2,185 mm
- Seat Height, Unladen 785 mm
- Ground Clearance 150 mm
- Rake 28.9
- Trail 140 mm
- Wheelbase 1,505 mm
- Tires, Front Specification 120/70R19 M/C
- Tires, Rear Specification 150/70R18 M/C
- Fuel Capacity 12.5 l
- Oil Capacity 2.6 l
- Weight, As Shipped 250 kg
- Weight, In Running Order 259 kg
Performance
- Engine Torque Testing Method J1349
- Engine Torque2 103 Nm
- Engine Torque (rpm) 3,750
- Lean Angle, Right (deg.) 30.8
- Lean Angle, Left (deg.) 31.1
- Fuel Economy: Estimated City/Hwy5 4.9 l/100 km
Drivetrain
- Primary Drive Chain, 38/57 ratio
- Gear Ratios (overall) 1st 9.315
- Gear Ratios (overall) 2nd 6.653
- Gear Ratios (overall) 3rd 4.948
- Gear Ratios (overall) 4th 4.102
- Gear Ratios (overall) 5th 3.517
Chassis
- Wheels, Front Type9 Black Offset, Split 5-Spoke Cast Aluminum
- Wheels, Rear Type Black Offset, Split 5-Spoke Cast Aluminum
- Brakes, Caliper Type Dual-piston front, Dual-piston rear
Electric
- Lights (as per country regulation), Indicator Lamps8 High beam, neutral, low oil pressure, turn signals, engie diagnostics, low fuel warning, low battery, security system (If equipped), ABS (if equipped)
- Gauges Dual Gauge – 4 “Digital Speedometer / Analog Tachometer
Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
