2019 KTM 1290 Super Duke R Guide

2019 KTM 1290 Super Duke R

2019 KTM 1290 Super Duke R 2019 KTM 1290 Super Duke R 2019 KTM 1290 Super Duke R 2019 KTM 1290 Super Duke R 2019 KTM 1290 Super Duke R 2019 KTM 1290 Super Duke R

THE BEAST 2.0 – NOTHING BUT THE BEST.

2019 KTM 1290 Super Duke R:

THE BEAST is not about mincing words or pulling punches. Blunt, brutal and extreme – there is nothing tame about this hyper-naked bike. With an updated design, mega powerful 1301 cc V-twin engine and exceptional all-round handling, the KTM 1290 SUPER DUKE R commands respect.

Hundreds of hours and thousands of test miles firmly cement KTM’s king of naked bikes on the cutting-edge of high-adrenaline motorcycling. Thanks to the sophisticated resonator chambers on the cylinder heads, designed to polish the torque output in the low to mid-engine speed range, the KTM 1290 SUPER DUKE R powertrain runs smoothly while delivering maximum power. Ultimately, it is the seemingly minor details that enhance power, such as the carefully optimized intake flange that alone widens the power band by 500 rpm. Every piece, system, nut and bolt of the SUPER DUKE R wants you to go fast and yet stay in control: the wide, low handlebar, the Brembo monobloc brakes, the MSC including cornering ABS, the glorious WP suspension, the optional, two-way Quickshifter+, the multifunctional TFT display and the LED headlight. The optional “Track Pack” including launch control, spin adjuster, a track ride mode, freely configurable ignition mapping and anti-wheelie off function. Then there is the optional “Performance Pack” to include motor slip regulation (MSR) and the Quickshifter+. The KTM MY RIDE smartphone and audio player integration comes now as standard. The optional anti-wheelie mode can disengage the anti-wheelie function of the MTC, and with the KTM RACE ON transponder key in your pocket, you can forget about ignition keys and mechanically locked fuel caps.









2019 KTM 1290 Super Duke R Totalmotorcycle.com Key Features

• Advanced 1,301cc LC8 V-Twin sets the standard in the naked segment in terms of horsepower and torque.
• Ultra-lightweight chrome-molybdenum steel trellis frame with bolt-on rear trellis subframe is light yet strong.
• 48mm USD split front forks by WP suspension with separate damping circuits offer composed handling on and off the track. Rebound and compression damping are adjustable.
• Fully-adjustable WP shock absorber balances the chassis with high speed composure.
• Metzeler M7RR super sport tires for high levels of grip and handling.
• MSC (Motorcycle Stability Control) with Cornering ABS by Bosch incl. Supermoto mode, Ride mode technology and multi-stage, lean angle sensitive Motorcycle Traction Control (MTC)
• Optional dealer-installed Performance Pack combines Motor Slip Regulation (MSR), Quickshifter+.
• KTM MY RIDE comes as standard and features a Bluetooth connection to the rider’s smart phone to control audio playback and to accept phone calls.
• Optional dealer-installed competition closed course only Track Pack with ‘Track’ ride mode which allows 3 Drive Modes, Anti-wheelie off, TC slip adjust and Launch control.
• Resonator chambers placed on the cylinder head for smoother power at low RPM.
• High compression ratio of 13.6:1 thanks to the flat design of machined titanium inlet valves with chromium nitride coating.
• LED headlight and LED daytime running lights for an aggressive front profile.
• Multifunctional TFT-dashboard displays all important information in a clear and bright display.
• Cruise control for long distance convenience.
• KTM RACE ON keyless system for less hassle and security.



MORE TOUR, MORE ROAR: 2019 KTM 1290 SUPER DUKE GT & R

KTM 1290 SUPER DUKE R
Already at the top of its game, for 2019 the mighty ktm 1290superduker receives a graphics update to keep it looking as sharp as it performs. This machine offers a unique technical layout with an awesome engine in a perfectly balanced chassis that delivers seemingly endless riding enjoyment in any situation and at any pace while distinguishing itself with exceptional levels of safety, not least because of cutting-edge high-tech solutions.

With an awesome 177 hp of maximum power, it wants riders to go fast yet stay in control: the wide, low handlebar, the Brembo monobloc brakes, the MSC including cornering ABS, competition-developed WP suspension, the optional, two-way Quickshifter+, the multifunctional TFT display and the LED headlight.

The optional “Track Pack” includes launch control, spin adjuster, three throttle response settings and anti-wheelie off function. Then there is the optional “Performance Pack” to include motor slip regulation (MSR) and the Quickshifter+. READY TO RACE, it is equipped with the RACE ON transponder key and the ktm MY RIDE smartphone and audio player integration.

Further additions to the ktm PowerParts range also provides riders with more options to intensify this incredible motorcycle, by enhancing and personalizing it in their vision – whether it is boosting aspects such as performance, practicality or style.

New for 2019, two new graphics – black or white – are the finishing touch to a super naked that is not all boast but definitely all Beast.





2019 KTM 1290 Super Duke R Totalmotorcycle.com Features and Benefits

ENGINE & EXHAUST
Launching THE BEAST forward at warp speed is a lightweight V-twin engine that is the most potent powerplant in its class. Weighing in at just 62 kg, it blasts out 132 kW (177 hp) and delivers its maximum 141 Nm of torque between 6750 rpm and 7000 rpm. No doubt then that it packs a fearsome punch for full-paced race attacks. Whether for street or racetrack use, it lays down bucket loads of pure, unadulterated performance.



ENGINE
HEART OF THE BEAST
Giving THE BEAST life is a 1301 cc V-Twin which pumps out an arm-wrenching 177 hp while its torque figures reach for the sky between 6,750 rpm (140 Nm) and 7,000 rpm (141 Nm). All in all, weighing in at around 62 kg, the extremely slim 4-valve unit makes it one of the lightest – and most powerful – big twins in the world.

EXHAUST
SOUND OF THUNDER
The KTM 1290 SUPER DUKE R’s exhaust system is made entirely from rustproof stainless steel and is Euro 4 homologated. Hundreds of test bench runs and complex simulation, ensured that the exhaust system contributes to the extremely smooth torque curve and excellent emission values on the V-twin. And did we mention the sound? While it whispers at low revs, it will take your breath away reaching for the high notes.



CHASSIS
Ultimate power requires total control. With its ultra-lightweight yet extremely stable trellis frame, a beautifully manufactured single-sided swing arm, high-end BREMBO brakes and state-of-the-art WP suspension components, the KTM 1290 SUPER DUKE R is the poster-boy for hooliganism. Paired with 17-inch tubeless wheels front and rear, and wrapped in METZELER M7RR tyres, THE BEAST tears into tarmac for maximum grip.



FRAMEWORK
BENEATH THE SKIN
With its ultra-lightweight yet extremely stable trellis frame, a beautifully manufactured single-sided swingarm, the KTM 1290 SUPER DUKE R exceeds all requirements for stability and control.

WHEELS
RUBBER-SIDE DOWN
A brace of METZELER M7RR tires on extremely lightweight, light-alloy wheels, the KTM 1290 SUPER DUKE R boasts some serious equipment as standard. Derived from METZELER’s experience in Road Racing activities, including the “Isle of Man TT”, they feature structure materials, compounds and a tread pattern for better wear, perfect steering and fantastic ride stability.

BRAKES
SPEED CLAMPS
Bringing this rampaging BEAST to a stop are two radially mounted BREMBO M50 Monobloc four-piston calipers and 320 mm discs. This is paired to an adjustable brake lever and powerful brake pump for easy single-finger modulation. Keeping things in check on the rear wheel is a 240 mm diameter disc and a two-piston BREMBO caliper.



ERGONOMICS & COMFORT
The powerful yet sophisticated engine in the KTM 1290 SUPER DUKE R enables hyper-sport propulsion or, when required, relaxed and comfortable riding – and everything in between. Pair that with fantastic suspension, geometry and rider aids, and the SUPER DUKE allows for unimaginable riding pleasure in all conditions at whatever speed you want, from very relaxed to very, very fast.



HANDLEBAR
TAMING THE BEAST
Taking the reins on the KTM 1290 SUPER DUKE R is via an upright, wide handlebar with allows riders 22 mm adjustment range with four positions. A set of adjustable hand levers complete the picture

FOOTPEGS
PERFECT POSITION
The traditional brake and gear shift lever you’d expect on a motorcycle, but with three-way adjustability for the gear shift & brake lever.



BODYWORK & GRAPHICS
Fresh decals, a sharp rear end, aggressive tank spoilers and air intakes, portrays the KTM 1290 SUPER DUKE R’s brutal attitude. The reduction of plastic parts shouts ‘NAKED’ and creates a BEAST that is always READY TO RACE.



BODYWORK
CONTROL STATION
Just like fighter pilots need information available to them at a moment’s notice, so do KTM 1290 SUPER DUKE R riders. The TFT display fitted to the SUPER DUKE R gives riders all the information they want at a moment’s glance. This means less time looking down, and more time looking ahead.

SOFTWARE & ELECTRONICS
Unrivaled braking from world market leader BREMBO, and assistance system MTC (Motorcycle Traction Control) and lean-angle sensitive ABS developed in close collaboration with BOSCH, round off the package and help the KTM 1290 SUPER DUKE R lead from start to finish. They allow you to either unleash the full potential of THE BEAST or to reign in its fury to easily and instantly adapt to changing riding conditions and personal needs, with the simple flick of a switch.



ACCESSORIES & LUGGAGE
Not enough for you? Well adding even more performance to this BEAST is only reserved for the brave! All KTM PowerParts are developed for their respective machines, meaning that KTM 1290 SUPER DUKE R riders only get parts that perfectly complement their ride and provide the same ‘factory fit’ straight from the dealer – allowing you to refine your BEAST’s functionality, look and feel to better fit your personal needs.







2019 KTM 1290 Super Duke R – Totalmotorcycle.com International Specifications/Technical Details
US MSRP Price: $ 18199 USD
Canada MSRP Price: $ See Dealer for Pricing in CDN
Europe/UK MSRP Price: £ See Dealer for Pricing in GBP (On The Road inc 20% Vat)
Australia MSRP Price: See Dealer for Pricing in AU
ENGINE
ENGINE TYPE 2-cylinder, 4-stroke, V 75°
DISPLACEMENT 1,301 cc
BORE / STROKE 108 / 71 mm
POWER 130 kW (177 hp) @ 9.750 rpm
TORQUE 141 Nm @ 7,000 rpm
COMPRESSION RATIO 13.6:1
STARTER / BATTERY Electric starter / 12V 12Ah
TRANSMISSION 6 gears
FUEL SYSTEM Keihin EFI (throttle body 56 mm)
CONTROL 8 V / DOHC
LUBRICATION Pressure lubrication with 3 Eaton pumps
ENGINE OIL Motorex, SAE 10W-50
PRIMARY DRIVE 40:76
FINAL DRIVE 17:38
COOLING Liquid cooling
CLUTCH PASC™ slipper clutch, hydraulically operated
ENGINE MANAGEMENT / IGNITION Keihin EMS with RBW and cruise control, double ignition
TRACTION CONTROL MTC (3-mode, disengageable, ‘Track’ mode opt.)
CHASSIS
FRAME Chromium-molybdenum-steel trellis frame, powder coated
SUBFRAME Chromium-molybdenum-steel trellis, powder coated
HANDLEBAR Aluminum, tapered, Ø 28 / 22 mm
FRONT SUSPENSION WP-USD Ø 48 mm
REAR SUSPENSION WP shock absorber
SUSPENSION TRAVEL FRONT / REAR 125 / 156 mm
FRONT BRAKE 2 × Brembo Monobloc four piston, radially mounted caliper, brake disc Ø 320 mm
REAR BRAKE Brembo two piston, fixed caliper, brake disc Ø 240 mm
ABS Bosch 9.1MP Two Channel (incl. supermoto mode, disengageable)
WHEELS FRONT / REAR Cast aluminum wheels 3.50 × 17″; 6.00 × 17″
TIRES FRONT / REAR 120/70 ZR 17; 190/55 ZR 17
CHAIN DID 525 5/8 × 5/16″
SILENCER Stainless steel primary and aluminum secondary silencer
STEERING HEAD ANGLE 65,1°
TRAIL 107 mm
WHEEL BASE 1,482 mm
GROUND CLEARANCE 141 mm
SEAT HEIGHT 835 mm
FUEL TANK CAPACITY approx. 18 liters / 3.6 liters reserve
DRY WEIGHT approx. 195 kg



Manufacturer Specifications and appearance are subject to change without prior notice on Total Motorcycle (TMW).
